1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
3. If applicable, remove the flex I/O connector board (see Flex I/O connector board on page 25).
Remove the ambient sensor:
■
Pull straight up to disconnect the ambient sensor from the system board.
NOTE: System board appearance can vary.
To install the ambient sensor, reverse the removal procedure.
Flex I/O connector board (board-to-board)
To remove the flex I/O connector board, use these procedures.
Table 4-10
Flex I/O connector board descriptions and part numbers
Description Spare part number
USB 3.1 Gen 1 ports (2) M09362-001
DisplayPort M45528-001
VGA M52136-001
HDMI N55107-001
Before removing the flex I/O connector board, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
3. If applicable, remove the flex I/O connector board (see Flex I/O connector board on page 25).
Remove the flex I/O connector board:
34
Chapter 4 Removal and replacement procedures
