5
2A8351-010
12) Use nylon ties to secure the silicone hose to the heated overow drain pan power cord above wire clamps B and C. See Fig. 9.
Be sure not to over tighten or pinch the silicone hose.
13) Remove the silicone hose from the heated overow drain pan. Conrm there are no kinks in the hose, then tighten the center nylon
tie. Be sure not to over tighten or pinch the silicone hose.
14) Measure the silicone hose so that the silicone hose extends a minimum of 1 in. (25 mm) into the heated overow drain pan but not
deep enough to touch the bottom of the heated overow drain pan. Once the correct amount of hose length is determined, mark the
distance needed and cut the silicone hose to that length.
B
C
Nylon Tie
Nylon Tie
Center
Nylon Tie
Heated Overow Drain
Pan Power Cord
Silicone Hose
Silicone Hose
Heated Overow
Drain Pan
Nylon Tie
Nylon Tie
Center
Nylon Tie
Silicone Hose
Heated Overow
Drain Pan
Heated Overow Drain
Pan Power Cord
Fig. 9
Model Shown: CF1S-FS
