ASSEMBLY
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 19
SSAT1000_230V | SSAT2200_230V
ASSEMBLY
14.1 Preparation
Check delivery content
Check the delivery immediately for transport damage and missing parts. Report any damage or
missing parts to your dealer or the shipping company immediately. Visible transport damage must
also be noted immediately on the delivery note in accordance with the provisions of the warranty,
otherwise the goods are deemed to have been properly accepted.
Requirements for the installation site
The selected installation site must ensure a suitable. Place the machine on a level, solid surface
that can support the weight of the machine. The chosen installation site of the machine must
comply with the local safety regulations as well as the ergonomic requirements for a workplace
with sufficient lighting conditions.
When calculating the required space, take into account that the operation, maintenance and
repair of the machine must be possible at all times without restrictions. Take into account the
space required for the machine to process the workpiece and any necessary work tables or
auxiliary stands.
NOTE
The floor at the installation site must be able to bear the load of the machine!
Preparation of the surfaces
Before putting the machine into operation, carefully remove the corrosion protection or grease
residues from the bare metal parts. This can be done with the usual solvents. Under no
circumstances should you use nitro thinners or other cleaning agents, as these can attack the
machine´s finish.
NOTE
The use of paint thinners, petro, aggressive chemicals or scouring agents will damage
the surfaces!
Therefore: Use only mild cleaning agents!
14.2 Assemble
NOTE
The machine and machine components are heavy!
2 persons are required to assemble the machine.
The machine comes pre-assembled, it is necessary to assemble the components dismantled for
transport according to the following instructions and to make the electrical connection.
Feet
• Position the machine on one long side
• Fix the feet to the underside of the machine (1)
- SSAT1000_230V: 4 feet
- SSAT2200_230V: 6 feet
• Place the machine on the feet and align horizontally.
Suction head
• Place the suction head (2) on the machine housing and
secure with Phillips screws (3)
Filter (if not already fitted)
• Position the filter to the blower housing (4)
- SSAT1000_230V: 2 filters
- SSAT2200_230V: 4 filters
