TRANSPORT
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at
20
MSM75_3IN1_230V | MSM75_3IN1_400V
WARNING
A safety instruction designed in this way indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION
A safety instruction designed in this way indicates a possibly hazardous situation
which, if not avoided, may result in minor or moderate injury.
NOTE
A safety notice designed in this way indicates a potentially hazardous situation which,
if not avoided, may result in property damage.
Regardless of all safety regulations, your common sense and your appropriate technical
aptitude/training are and remain the most important safety factors in the error-free operation of
the machine. Safe working depends on you!
TRANSPORT
Transport the machine in its packaging to the place of installation. To manoeuvre the machine in
the packaging, a pallet truck or forklift truck with the appropriate lifting force can be used, for
example. The specifications can be found in the chapter Technical data. For proper transport, also
observe the instructions and information on the transport packaging regarding centre of gravity,
lifting points, weight, means of transport to be used as well as the prescribed transport position
etc. Ensure that the selected lifting equipment (crane, forklift, pallet truck, load sling, etc.) is in
perfect condition.
Lifting and transporting the machine may only be carried out by qualified personnel with
appropriate training for the lifting equipment used. Ensure that the load is secured.
• To lift the machine with a forklift truck, you need a forklift truck with the
appropriate load capacity and a fork at least 1200 mm long.
• The machine must be positioned on a pallet.
• To lift/transport the machine, thread the fork of the forklift truck into the
pallet (1).
• Prepare the rope or a rope with the appropriate load capacity and
length for lifting the machine with a crane.
• Attach the rope to the crane hook and transport eye (2)
• Position the crane in such a way that stable lifting of the machine
without tipping is guaranteed.
• Lift the machine gently to avoid impacts and load fluctuations and
transport it carefully to the installation site.
ASSEMBLY
14.1 Preparation
Check delivery content
Check the delivery immediately for transport damage and missing parts. Report any damage or
missing parts to your dealer or the shipping company immediately. Visible transport damage must
also be noted immediately on the delivery note in accordance with the provisions of the warranty,
otherwise the goods are deemed to have been properly accepted.
Requirements for the installation site
Place the machine on a level, solid surface that can support the weight of the machine. The
machine may only be used in a dry and well-ventilated room and not in the vicinity of dust and
chip-generating machines. The selected installation location must ensure a suitable connection to
the power supply. The chosen installation site of the machine must comply with the local safety
regulations as well as the ergonomic requirements for a workplace with sufficient lighting
conditions.
NOTE
The floor at the installation site must be able to bear the load of the machine!
WARNING
Risk of injury from suspended or unsecured load!
Damaged or insufficiently strong hoists and load slings can result in serious injury or
even death.
• Before use, therefore, check hoists and load slings for adequate load-bearing
capacity and perfect condition.
• Secure the loads carefully.
• Never stand under suspended loads!
