OPERATION
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 29
EISA160MINI
Reference values for fillet welds on unalloyed and low-alloy steels
Eff. throat
thickness
Welding
position
Electrode type
Ø Electrode in mm
Current intensity in A
2 mm
PG
RC
2,5
70
3 mm
PB
RR
3,2
130
4,0
180
4 mm 190
RR160
5 mm RR
180
5,0
240
6 mm
RR160
290
RR
4,0
180
5,0
240
8 mm PF B
3,2 110
4,0 140
Reference values for butt welds on pipes made from unalloyed and low-alloy steel
Wall
thickness
Welding
position
Electrode type
Ø Electrode in mm
Current intensity in A
8 mm
PG C
4,0 125 - 170
10 mm
4,0
130 - 150
5,0 175 - 190
4,0
130 - 180
12 mm 5,0 175 - 200
15.3 Operating the machine
WARNING
Danger due to electrical voltage!
Handling the machine with connected power supply may result in serious injury or
death.
Always disconnect the machine from the power supply before maintenance or
repair work and secure it against unintentional reconnection.
CAUTION
Danger of personal injury and damage to property due to electric shock.
As soon as the machine is switched on, the electrode is live. Make sure that the
electrode does not touch any persons or electrically conductive or earthed parts (e.g.
housing, etc.).
15.3.1 Switch the machine on and off
Position I: Switch on
Position 0: Switch off
