OPERATION
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 28
EISA160MINI
Codes for efficiency and current type
Code
Efficiency
Current type
1
≤105 %
AC and DC
2
DC
3
>105 % ≤ 125%
AC and DC
4
DC
5
>125 % ≤ 160%
AC and DC
6
DC
7
< 160 %
AC and DC
8
DC
Codes for position
Code
Position
1
All positions
2
all positions except vertical-down
3
Butt weld in position PA, fillet weld in position PA and PB
4
Butt weld in position PA, fillet weld in position PA
5
Positions as for 3 plus position PG
Codes for the hydrogen content of the weld metal
Code
Hydrogen content of weld metal
H5
max. 5 ml/100g
H10
max. 10 ml/100g
H15
max. 15 ml/100g
Example:
E
46
3
B
4
2
H5
stick electrode
strength and
expansion
properties
notch
impact
energy
coating
current
type
position
hydrogen
content
Reference values for butt welds on unalloyed and low-alloy sheet materials
Sheet
thickness
Welding
position
Elektrode type
Ø Electrode in mm
Current intensity in A
4 mm
PA
RA
2,5
75
6 mm
3,2
140
4,0 180
10 mm
B
3,2
120
4,0 170
PF RB
3,2
95
4,0 160
15 mm
PA B
3,2
130
4,0 170
PF B
3,2
90
4,0
140
20 mm
PA B
4,0
160
5,0
220
PF B
3,2
90
4,0
140
