*2321725*
2321725 5
• For this product, use only Hilti Nuron lithium-ion batteries of the B 22 series. For optimum performance, Hilti recommends the batteries
stated in the table at the end of these operating instructions for this product.
• For these batteries, use only Hilti chargers of the type series stated in the table at the end of these operating instructions.
Possible misuse
• Do not use this hand-held crimping tool clamped in a fixed position or as a stationary device.
• Do not use the electro-hydraulic crimping tool in heavy rain or under water.
Coated crimping head
NCR 60 DC-22
DANGER
Electricity presents a risk of fatal accident! Contact with electrically live lines can lead to severe physical injury and/or death.
▶ The crimping tool is not insulated! If you use this crimping tool in the vicinity of electrically live lines, wear personal protective equipment.
The crimping head of the NCR 60DC-22 has a PVC coating. The PVC coating is red, the housing underneath is colored black.
Before each use, inspect the red coating on the crimping head for indications of damage or aging. If you find such damage, the black
surface of the housing is visible and/or the crush-hazard or electric-shock hazard symbol is no longer legible, do not use the crimping
tool and contact Hilti Service.
Status indicators of the Liion battery
Hilti Nuron Li-ion batteries can indicate state of charge, fault messages and the battery's state of health.
Indicators for state of charge and fault messages
WARNING
Risk of injury by a falling battery!
▶ If the release button is pressed with a battery inserted in the product, subsequently check that the battery is correctly re-engaged and secure.
Short-press the release button of the battery to get whichever of the following status indications is applicable at the time.
State of charge and, if applicable, faults are indicated constantly as long as the connected product is switched on.
Status Meaning
Four (4) LEDs show constantly green State of charge: 100 % to 71 %
Three (3) LEDs show constantly green State of charge: 70 % to 51 %
Two (2) LEDs show constantly green State of charge: 50 % to 26 %
One (1) LED shows constantly green State of charge: 25 % to 10 %
One (1) LED slow-flashes green State of charge: < 10 %
One (1) LED quick-flashes green The Li-ion battery is completely discharged. Recharge the battery.
If the LED again starts quick-flashing after the battery has been
charged, consult Hilti Service.
One (1) LED quick-flashes yellow The Li-ion battery or the product in which it is inserted is overload-
ed, too hot or too cold, or experiencing some other fault.
Bring the product and the battery to the recommended working
temperature and do not overload the product when it is in use.
If the message persists, consult Hilti Service.
One (1) LED shows yellow The Li-ion battery and the product in which it is inserted are not
compatible. Consult Hilti Service.
One (1) LED quick-flashes red The Li-ion battery is locked and cannot be used. Consult Hilti Ser-
vice.
Indicators showing the battery's state of health
To check the battery's state of health, press the release button and hold it down for longer than three seconds. The system does not detect a
potential malfunction of the battery due to misuse, for example battery dropped or pierced, external heat damage, etc.
Status Meaning
All LEDs show in sequence, followed by one (1) LED showing con-
stantly green.
The battery can remain in use.
All LEDs show in sequence, followed by one (1) LED quick-flashing
yellow.
The check to ascertain the battery's state of health did not com-
plete. Repeat the procedure, or consult Hilti Service.
All LEDs show in sequence, followed by one (1) LED showing con-
stantly red.
If a connected product can still be used, the remaining battery ca-
pacity is below 50 %.
If a connected product can no longer be used, the battery has
reached the end of its useful life and has to be replaced. Consult
Hilti Service.
