6 2321725
*2321725*
Items supplied
Crimping tool, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or at: www.hilti.group
Selection of the connecting material
A table to assist with selecting the type of cable and cable terminal to be used can be found at the end of these operating instructions.
Technical data
NCR 60 DC-22 NCR 60 D-22
Product generation
02 02
Rated voltage
21.6 V 21.6 V
Weight without battery
5.3 lb
(2.4 kg)
5.3 lb
(2.4 kg)
Max. crimping / pressing force
6,744 lb
f
… 13,489 lb
f
(30 kN … 60 kN)
6,744 lb
f
… 13,489 lb
f
(30 kN … 60 kN)
Crimping / pressing time
≈ 5 s ≈ 5 s
Max. permissible crimping capacity Cu standard strand
500 MCM 500 MCM
Cu fine strand
350 MCM 350 MCM
Al
350 MCM 350 MCM
Storage temperature
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
Ambient temperature for operation
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
Battery
Battery operating voltage
21.6 V
Weight, battery
See the end of these operating instructions
Ambient temperature for operation
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
Storage temperature
−4 ℉ … 104 ℉
(−20 ℃ … 40 ℃)
Battery charging starting temperature
14 ℉ … 113 ℉
(−10 ℃ … 45 ℃)
Preparations at the workplace
WARNING
Risk of injury by inadvertent starting!
▶ Before inserting the battery, make sure that the product is switched off.
▶ Remove the battery before making any adjustments to the power tool or before changing accessories.
WARNING
Risk of injury! If not aligned flush, lever and pivoting bar can fly out like projectiles.
▶ Before and during the crimping operation, make sure that lever and pivoting bar are correctly aligned.
CAUTION
Risk of injury! The accessory tool may be hot and/or have sharp edges.
▶ Wear protective gloves when changing the accessory tool.
▶
Never lay down a hot accessory tool on a flammable surface.
Observe the safety instructions and warnings in this documentation and on the product.
Charging the battery
1. Before charging the battery, read the operating instructions for the charger.
2. Make sure that the contacts on the battery and the contacts on the charger are clean and dry.
3.
Use an approved charger to charge the battery. 4
