*2321725*
2321725 7
Inserting the battery
WARNING
Risk of injury by short circuit or falling battery!
▶ Before inserting the battery, make sure that the contacts on the battery and the contacts on the product are free of foreign matter.
▶ Make sure that the battery always engages correctly.
1. Charge the battery fully before using it for the first time.
2. Push the battery into the product until it engages with an audible click.
3. Check that the battery is seated securely.
Removing the battery
1. Press the battery release button.
2. Remove the battery from the product.
Switching starting lock on/off
The crimping tool has a starting lock that can be optionally activated or deactivated. If the starting lock is activated, the control switch has to
be pressed twice to start the crimping operation. This prevents inadvertent starting.
The factory default is starting lock deactivated.
1.
Remove the battery. 7
2. Press and hold down the control switch.
3. Insert the battery into the crimping tool.
4. Release the control switch.
▶ The green LED flashes twice; acoustic signal sounds twice: starting lock activated
▶ Green LED flashes once; acoustic signal sounds once: starting lock deactivated
Fall arrest
WARNING
Risk of injury by falling tool and/or accessory!
▶ Use only the Hilti tool tether recommended for your product.
▶ Prior to each use, always check the attachment point of the tool tether for possible damage.
Comply with the national regulations for working at heights.
As drop arrester for this product, use only a combination of the Hilti retaining strap #2293133 and the Hilti tool tether #2261970.
▶ Secure the retaining strap to the installation openings for accessories. Check that it holds securely.
▶ Secure one carabiner of the tool tether to the retaining strap and secure the second carabiner to a load-bearing structure. Check that both
carabiners hold securely.
Comply with the operating instructions of the Hilti retaining strap and those of the Hilti tool tether.
Operation
Observe the safety instructions and warnings in this documentation and on the product.
Performing crimping operation 2
DANGER
Electric shock hazard! Working in adverse outdoor conditions can cause electric shocks and/or short circuits.
▶ Never work on electrically live lines while a thunderstorm is in progress.
▶ Call a halt to work immediately whenever weather conditions impair the insulation characteristics, vision or movement of the workers.
WARNING
Risk of burn injury due to faulty crimping operations. Burns can result.
▶ Use crimping terminals of the correct type and size for the cable and use with the corresponding crimping dies.
▶ Before every crimping operation, make sure that pivoting bar and lever are securely engaged.
▶ Listen for the acoustic signal and check that the piston has retracted. If no acoustic signal sounds and/or the piston does not retract, the
crimping operation is faulty.
WARNING
Risk of injury due to oil escaping under high pressure! Oil escaping under high pressure can injure the skin and the eyes.
▶ Do not use the crimping tool if damage is visible.
▶ Do not use the crimping tool if oil escapes.
▶ Make sure that the piston retracts after every crimping operation.
▶ If the piston does not retract after the crimping operation, press the piston return switch for manual retraction.
