08.12.2021 08.12.2021
6 7
DE ENUSER MANUAL
Parameter
description
Parameter
value
Product name FOLDING GARDEN CART
Model HT-TWIN 300 HT-TWIN 550
Maximum
load [kg]
300 550
Diameter of
wheels
10”x3,5 10”x5
Length of the
handle [mm]
785 788
Dimensions
[mm]
1150x515x885 1390x620x955
Weight [kg] 17,3 27
REINIGUNG UND WARTUNG
a) Verwenden Sie zur Reinigung der Oberäche
ausschließlich Mittel ohne ätzende Inhaltsstoe.
b) Bewahren Sie das Gerät an einem trockenen, kühlen,
vor Feuchtigkeit und direkter Sonneneinstrahlung
geschütztem Ort auf.
c) In Hinblick auf technische Ezienz und zur
Vorbeugung vor Schäden sollte das Gerät regelmäßig
überprüft werden.
d) Zum Reinigen ist ein weicher, feuchter Lappen zu
verwenden.
e) Überprüfen Sie regelmäßig den Reifendruck.
TECHNICAL DATA
GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
USE GUIDELINES
The folding garden trolley is designed for transporting
plants, soil and garden accessories.
The user is liable for any damage resulting from
unintended use of the device.
LEGEND
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
ACHTUNG! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there
is still a slight risk of accident or injury when using
the device. Stay alert and use common sense when
using the device.
The original operation manual is written in German. Other
language versions are translations from the German.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
Read instructions before use.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation. (general
warning sign).
The terms "device" or "product" are used in the warnings
and instructions to refer to FOLDING GARDEN CART.
USAGE SAFETY
DEVICE DESCRIPTION
HT-TWIN 300
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
death.
a) If you are unsure about whether the product is
operating correctly or if you nd damage, please
contact the manufacturer’s service centre.
b) Keep the device in perfect technical condition.
Before each use check for general damage and
especially check for cracked parts or elements and
for any other conditions which may impact the safe
operation of the device. If damage is discovered,
hand over the device for repair before use.
c) Device repair or maintenance should be carried out
by qualied persons, only using original spare parts.
This will ensure safe use.
d) Do not put more than 300kg (HT-TWIN 300) / 550kg
(HT-TWIN 550) into the load area.
e) The product is not intended for children, it is not
a toy.
f) Distribute the load weight evenly over the entire
surface.
g) In case of damage or destruction of any of the
components, it is necessary to cease using them.
h) Do not use the truck on surfaces / areas that may
cause damage of tires.
i) The tire ination pressure must not exceed 40 PSI.
1 Trolley base 1x
2 Side panel 2x
3 Front/rear panel 2x
4 Front hook 1x
5 Handle 1x
6 Wheel 4x
7 Front bracket 1x
8 Rear bracket 1x
9 "B" pin 8x
10 M8x15 screw 8x
11 Pin 5x
12 M8 washer 9x
13 M16 washer 5x
14 M8 nut 9x
15 M8x58 screw 1x
16 Plastic joint 1x
