Hardware conguration
High Voltage Range conguration:
Highlevel: 8 - 32 Volts
Line (RCA / Cinch): 2 - 8 Volts
Input sensitivity is factory set to 11.3 Volts
(highlevel) and 2.8 Volts (Line / RCA / Cinch).
This is denitely the best setting in most ap-
plications.
If the signal source provides a lower output
voltage, the input sensitivity can be increased
via the DSP PC-Tool.
If your signal source delivers a higher output
voltage – for example, if a factory-installed
amplier serves as signal source – the input
sensitivity must be lowered and the correct
conguration of the “Voltage Range” jumpers
must be checked (see page 22, point 1).
If you are not sure regarding the signal sourc-
es output voltage, please contact your HELIX
specialist dealer.
Note: Do not connect any speakers to the
outputs of the amplier during this setup and
switch o any connected ampliers.
Therefore follow the subsequent steps:
1. Turn on the amplier and then start the
software. The function can be found in the
“Input” tab in the sub-menu “Gain Congu-
ration”.
2. Select the setup method to adjust the input
sensitivity.
Standard Gain Setup: This method allows
for global adjustment of input sensitivity for
all input channels (can only be selected if
all jumpers are set to “Low Voltage Range”
or “High Voltage Range” position – see
page 22, point 1).
Advanced Gain Setup: This method allows
individual conguration of each channel
pair.
3. Adjust the volume of your radio to approx.
90 % of the maximum volume and play
back a suitable test signal – ideally our spe-
cially developed “IGS – Input Gain Setup”
signal, which can be found under “Audio
Test Tracks” in the DSP PC-Tool or down-
loaded from www.audiotec-scher.com.
4.
Normally, the clipping indicator in the DSP
PC-Tool is o (gray) and only lights up if one
of the analog inputs is overdriven.
Now increase the input sensitivity using the
scroll bar until the clipping indicator lights up
red
(see the following picture).
5. Then turn the control back one step until
the clipping indicator turns o again.
6. Standard Gain Setup: The process is now
complete.
Advanced Gain Setup: Repeat this pro-
cess for each input channel pair used.
Various adjustment examples of the input
sensitivity can be found on page 28. For
further applications please contact your
HELIX specialist dealer.
