25
en
110 A). If your power wires are short (less
than 1 m / 40”) then a wire gauge of 16 mm² /
AWG 6 will be sucient. In all other cases we
strongly recommend gauges of 25 - 35 mm² /
AWG 4 – 2!
GND: Connector for the ground cable. The
ground wire should be connected to a com-
mon ground reference point (this is located
where the negative terminal of the battery is
grounded to the metal body of the vehicle) or
to a prepared metal location on the vehicle
chassis, i.e., an area cleaned of all paint resi-
dues. The cable should have the same gauge
as the +12 V wire. Inadequate grounding
causes audible interference and malfunctions.
REM: The remote input is used to switch on
the V EIGHT DSP ULTIMATE if the pre-am-
plier inputs or digital input are / is used. If
the signal source connected to the highlevel
input does not activate the “automatic turn-on”
function or the amplier is to be deliberately
switched on and o only via a remote signal,
this input must be assigned. The remote wire
should be connected to the remote output /
automatic antenna (aerial positive) output of
the head unit / car radio. This is only activated
if the head unit is switched on. Thus the am-
plier is switched on and o together with the
head unit.
We do not recommend controlling the remote
input via the ignition switch to avoid pop noise
during turn on / o.
Note: This input does not need to be assigned
if the highlevel input is used. To deactivate the
“automatic turn-on” function read the descrip-
tion on page 24 in point 5 “Conguration of the
remote input”.
7. Connecting the PC & rst start-up
The USB-C input enables the connection of
the V EIGHT DSP ULTIMATE to a personal
computer and its free conguration with our
DSP PC-Tool software using the provided
USB-C cable (see page 22, g. 1). If your
computer only has a USB-A port, use the
USB-C to USB-A adaptor also supplied.
Please note: It is not possible to connect any
USB storage devices.
Before you connect the V EIGHT DSP
ULTIMATE to a computer for the rst time,
download the latest DSP PC-Tool software (at
least version 6) from our homepage. The soft-
ware and a comprehensive knowledge base
can be found at www.audiotec-scher.com.
It is advisable to check regularly for software
updates so that the device is always up to
date. We strongly recommend to carefully
read the DSP PC-Tool knowledge base before
using the software for the rst time in order to
avoid any complications and failures.
Important: Make sure that the amplier is not
connected to your computer before the soft-
ware and USB driver are installed!
In the following the most important steps how
to connect and the rst start-up are described:
1. Download the latest version of the DSP
PC-Tool software (available on our web-
site www.audiotec-scher.com) and in-
stall it on your computer.
2. Connect the amplier to your computer us-
ing the USB cable that is included in deliv-
ery. If you have to bridge longer distances
please use an active USB extension cable
with integrated repeater.
3. First turn on the amplier and then start the
software. The operating software will be
updated automatically to the latest version
if it is not up-to-date.
8. Adjustment of the input sensitivity of the
analog signal inputs
ATTENTION: It is mandatory to properly
adapt the input sensitivity of the V EIGHT DSP
ULTIMATE to the signal source in order to
achieve the best possible signal quality and
to avoid damage to the amplier. It is also
mandatory to adjust the “Voltage Range” to
the output voltage of your signal source (see
page 22, point 1).
The input sensitivity of each channel pair can
be optimally adapted to the signal source us-
ing the DSP PC-Tool software.
The setting of the controls aects both the
lowlevel and the highlevel inputs!
The gain control ranges are:
Low Voltage Range conguration:
Highlevel: 4 - 16 Volts
Line (RCA / Cinch): 1 - 4 Volts
