9. Conguration of the internal DSP
IMPORTANT: The general DSP settings
should be conducted with the DSP PC-Tool
software before using the amplier for the
rst time. Now you are able to congure your
V EIGHT DSP ULTIMATE with our intuitive
DSP PC-Tool software. Useful hints for the
correct setting can be found in our knowledge
base at www.audiotec-scher.com.
Caution: We highly recommend to set the
volume of your car radio to minimum position
during rst start-up. Additionally no devices
should be connected to the amplier. Espe-
cially if the V EIGHT DSP ULTIMATE will be
used in fully active applications, a wrong setup
can destroy your speakers right away.
10. Optional: Analyzing the input signal
When using the highlevel input, we recom-
mend analyzing the input signal with the Ad-
vanced Input Signal Analyzer (AISA) in the
DSP PC-Tool. This helps detect and correct
factory-set equalization, time alignment, or all-
pass lters if present.
Thanks to the new PerfectStream function
of the current ACO platform, no additional
measuring equipment is required for this. The
measurement signals are transmitted directly
to the computer without loss via the USB-C
interface (page 21, point 1) of the amplier.
Information on the AISA can be found in the
extensive Knowledge Base on our website
www.audiotec-scher.com.
11. Connecting the loudspeaker outputs
The loudspeaker outputs can be connect-
ed directly to the wires of the loudspeakers.
Never connect any of the loudspeaker cables
with the chassis ground as this will damage
your amplier and your speakers. Ensure that
the loudspeakers are correctly connected (in
phase), i.e. plus to plus and minus to minus.
Exchanging plus and minus causes a total
loss of bass reproduction. The plus pole is in-
dicated on most speakers. The impedance of
the speakers of the channels 1 - 4 must not
be lower than 4 Ohms (absolute minimum
3 Ohms). All other channels can be loaded
with a minimum of 2 Ohms. The speaker out-
puts are not bridgeable. For subwoofer appli-
cations ideally use drivers with dual voice coil
(2 x 2 Ohms).
Attention: Solely use the supplied connection
cable with the 8-pin plug and ying leads for
connecting the speaker outputs 1 to 4 (see
page 22, g. 1).
12. Optional
: Connecting the line outputs
The six pre-amplier outputs (LINE OUTPUT)
can now be connected to the RCA / Cinch in-
puts of the external ampliers using appropri-
ate cables (RCA / Cinch cables).
The outputs provide a maximum output volt-
age of 3 Volts RMS. When using one of these
outputs, it is essential to use one of the remote
outputs (REM OUT) to switch on an addition-
ally connected amplier, as otherwise interfer-
ence noise may occur.
Attention: Solely use the supplied connection
cable for connection (see page 22, g. 1)
13. Optional: Connecting the remote outputs
The remote outputs are used for turning
on / o ampliers that are connected to the
line outputs of the V EIGHT DSP ULTIMATE.
Therefore connect the remote output of the
V EIGHT DSP ULTIMATE to the remote input
of your ampliers to switch it on and o via the
internal DSP without interfering signals. The
remote outputs are activated automatically
as soon as the booting process of the DSP is
completed. Additionally these outputs will be
turned o during the “Power Save Mode” or a
software update process.
Important: Never use a dierent signal
than the remote output of the V EIGHT DSP
ULTIMATE to activate a connected amplier!
14. Sound tuning
Now you can create your sound setup.
Information about sound tuning can be
found in our extensive knowledge base at
www.audiotec-scher.com or contact your
local HELIX dealer.
