Set-up, connection and initial start-up Page EN-13
90°
600 mm
820–870 mm
100 mm
570 mm
80 mm
90°
Area for inflow/
Outflow and electrical
connection.
– Only install the dishwasher underneath
a continuous worktop which is joined to
the cabinets adjacent to the dishwasher.
– Maintain sufficient distance from the
walls and adjacent appliances. The
measurements of the recess must at
least correspond to the details in the dia-
gram above.
Preparing the appliance
1. Switch the fuse off.
2. Remove cardboard, polystyrene and
adhesive strips from the inside of the
appliance, if you have not already done
so.
(36)
3. Glue the enclosed protective film for
condensation water (36) to the under-
side of the worktop. This will prevent
damage to the worktop caused by hot
steam released from inside the dish-
washer when the appliance door is left
open.
Placing the appliance in the niche
1. Make sure that the inlet hose (21), the
outlet hose (19) and the mains cord
with the mains plug (20) are routed cor-
rectly.
(32)
2. Attach 4 mounting brackets (32) to both
sides of the appliance with the pre-as-
sembled screws, in order to screw the
appliance to the side kitchen cabinets
later.
3. Slide the appliance into the recess.
