39
GYSFLASH 108.12 / 148.12 / 158.12 CNT FV
EN
39
Gysash 1 Gysash 2
System
being
supplied
Gysash 1
System
being
supplied
Gysash 2
X
OK NOK
• Method n°2 : With parallelisation modules (PHM + SHM) Multi-charger Mode
These Gysash units can also be parallelized using an SHM module, which manages communication between the
various Gysashes (via the SMC ports) and a PHM module, which connects the various power outputs together to
form a single, more powerful output.
See the SHM and PHM parallelisation module manuals for more details on installation and use.
Note: The Gysash units connected must be identical.
Compatible modes:
CHARGE SUPPLY AUTO-SELECT POWER-UP
SHM
PHM
Communication
Power
I1
Master Slave 1 Slave 2 Slave 3
I2
I3 I4
I1 + I2 + I3 + I4
System
being
supplied
