Je bekijkt pagina 15 van 24
13
DMX SETTINGS
DMX SETTINGS
DMX Address
DMX Mode
MENU
③ Menu Page :
Press the [MENU] button to enter the menu setting page. Rotate [Knob 1] to select a
sub menu. Press [Knob 1] to enter the corresponding menu page → Press or rotate
[Knob 1] to set parameters → Press [BACK] key to return to the previous menu.
DMX SETTINGS:
DMX Address: Set the address parameters of the DMX.
DMX Mode: Select the DMX mode.
Color Gels (GEL)
This mode offers two types of color gel standards,
ROSCO and LEE, each with 30 color gel presets.
INT: indicates the brightness level of the gel preset.
3200K/5600K: Select the color temperature of the
light.
LEE/ROSCO: Select the color gel standards.
GEL: Select the specific color gels.
Light Source Mode (Source)
This model offers 12 light source presets: tungsten
lamp, 5600 dysprosium lamp, daylight dysprosium
lamp, studio lamp, Sodium Vapor lamp, halogen
lamp, short arc gas lamp, candlelight, sunrise/sunset,
daytime, cloudy day, fluorescent cold white.
INT: indicates the brightness level of the preset.
② APP/DMX/RF control :
You can choose from five lighting modes: CCT, HSI, RGB, Color
Paper, and Light Source. Additionally, you can access 16 simulated
lighting effects for versatile creative control.
1
CCT 8-bit(2ch)
CCT 16-bit(4ch)
CCT+Ctrl 8-bit(4ch)
CCT+Ctrl 16-bit(6ch)
DMX Address DMX Mode
LIGHT
LIGHT
GEL
Source
GEL
L002 Rose Pink
L007 Pale Yellow
L019 Fire
L021 Gold Amber
L025 Sunset Red
L026 Bright Red
Source
Tungsten
INT
50.0%
5600K
3200K
ROSCO
LEE
INT
50.0%
