12
FUNCTION INTRODUCTION &
INSTRUCTIONS FOR USE
There are five lighting modes: CCT, HSI, RGB, color gels, and light source match.
1．Press the [MODE] button to enter the main page of mode selection → Rotate [Knob 1]
to go through selections → Rotate [Knob 1] to select mode → Press [Knob 1] to enter
the corresponding mode interface.
2．Rotate [Knob 2] to adjust the brightness of the light → Rotate [Knob 1] to select the
parameter type → Press [Knob 1] to confirm the parameter type selection → Rotate
[Knob 1] to set the currently selected parameter.
3．Press [BACK] to return to the previous menu.
① CCT Mode :
Color Temperature Mode (CCT)
Color Temperature Mode: Allows adjustment of the
light’s color temperature from 2000K to 10000K.
INT: Represents the brightness level of the light.
CCT: Represents the color temperature setting of the light.
G/M: Adjusts the green/magenta offset for precise color correction.
Tone Color Light Mode (HSI)
By adjusting the hue, saturation, and brightness to
achieve up to 36 million color combinations.
INT: indicates the brightness parameter of the light.
HUE: indicates the hue parameter of a light.
SAT: Saturation percentage of the light.
Red Green Blue Light Mode (RGB)
By adjusting the red ( R ), green ( G ), and blue ( B ) light settings, the color of the light
10
can be finely tuned, allowing for up to 16 billion ( 1.6 × 10 ) possible colors.
INT: Controls the brightness level of the light.
R: Adjusts the intensity of the red light.
G: Adjusts the intensity of the green light.
B: Adjusts the intensity of the blue light.
CCT
HSI
RGB
LIGHT
LIGHT
LIGHT
CCT
INT
50.0%
CCT
5600K
G/M
0
HSI
INT
50.0%
HUE
SAT
0
100%
RGB
GR
255
B
INT
50.0%
255 255
