17 EU Declaration of conformity
With the scope of EU directives:
•2014/35/EU Low Voltage Directive (LVD)
•2014/30/EU Electromagnetic Compatibility Directive (EMC)
•2011/65/EU RoHS Directive and its amendment (EU)2015/863
Shenzhen Growatt New Energy Technology Co. Ltd confirms that the Growatt
inverters and accessories described in this document are in compliance with the
above mentioned
EU directives. The entire EU Declaration of Conformity can be found at
www.ginverter.com.
18.1 Parameter
Specification 18
Model
Specifications
MID
17KTL3-X1
MID
20KTL3-X1
MID
22KTL3-X1
MID
25KTL3-X1
Input data(DC)
Max. recommended PV power(for
module STC)
25500W
30000W
33000W
37500W
Max. DC voltage
1100V
Start voltage
250V
Min. operating voltage
200V
Nominal voltage
600V
MPP voltage range
200-1000V
No. of MPP trackers
3
No. of PV strings per MPP
trackers
2/2/2
2/2/2
2/2/2
2/2/2
Max. input current per MPP
trackers
26A*3
26A*3
26A*3
26A*3
Max. short-circuit current per
MPP trackers
32A*3
32A*3
32A*3
32A*3
Backfeed current to PV array
0A
Output data(AC)
Rated output power
17kW
20kW
22kW
25kW
Rated apparent power
17kVA
20kVA
22kVA
25kVA
Max. AC apparent
18.8kVA
22.2kVA
24.4kVA
27.7kVA
Nominal AC voltage/range
230/400V
340-440V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated output current
24.6A
29.0A
31.9A
36.2A
Max. output current
28.6A
33.7A
37.0A
42.1A
Max output overload protection
40A/230V
40A/230V
50A/230V
50A/230V
Max. inrush current(Peak
value/duration time)
29A/2ms
32A/2ms
34A/2ms
38A/2ms
AC inrush current
60A
Max. output fault current(Peak
value/duration time)
113.3A/10us
Max. output fault current
106.1A
Max. output overcurrent
Protection
106.1A
Power factor(@nominal power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Efficiency
Max. efficiency
98.75%
98.75%
98.75%
98.8%
Euro-eta
98.5%
98.5%
98.5%
98.5%
49
50
