51
52
Model
Specifications
MID
17KTL3-X1
MID
20KTL3-X1
MID
22KTL3-X1
MID
25KTL3-X1
Protection devices
DC reverse-polarity protection
YES
DC switch
YES
DC Surge protection
typeII OPT
Insulation resistance monitoring
YES
AC surge protection
typeII OPT
AC short-circuit protection
YES
Grid monitoring
YES
Anti-islanding protection
Integrated(Active Frequency Drift)
Residual-current monitoring unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in mm
580*435*230mm
Weight
30.0kg
Operating temperature range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤50dB(A)
Altitude
4000m
Internal consumption at night
1W
Topology
Non-isolated
Cooling
Smart air cooling
Electronics protection degree
IP66
Relative humidity
0~100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
Model
Specifications
MID
30KTL3-X
MID
33KTL3-X
MID
36KTL3-X
MID
40KTL3-X
Input data(DC)
Max. recommended PV power(for
module STC)
45000W
49500W
54000W
60000W
Max. DC voltage
1100V
Start voltage
250V
Min. operating voltage
200V
Nominal voltage
600V
MPP voltage range
200-1000V
No. of MPP trackers
3
4
No. of PV strings per MPP
trackers
2/2/2
2/2/2
2/2/2/2
2/2/2/2
Max. input current per MPP
trackers
26A*3
26A*3
26A*4
26A*4
Max. short-circuit current per
MPP trackers
32A*3
32A*3
32A*4
32A*4
Backfeed current to PV array
0A
Output data(AC)
Rated output power
30000W
33000W
36000W
40000W
Rated apparent power
30000VA
33000VA
36000VA
40000VA
Max. AC apparent
33300VA
36600VA
40000VA
44400VA
Nominal AC voltage/range
230/400V
340-440V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated output current
43.5A
47.8A
52.2A
58.0A
Max. output current
50.5A
55.6A
60.6A
67.3A
Max output overload protection
80A/230V
80A/230V
100A/230V
100A/230V
Max. inrush current(Peak
value/duration time)
41A/2ms
46A/2ms
52A/2ms
57A/2ms
AC inrush current
60A
Max. output fault current(Peak
value/duration time)
113.3A/10us
113.3A/10us
132.2A/10us
132.2A/10us
Max. output fault current
106.1A
106.1A
124.8A
124.8A
Max. output overcurrent Protection
106.1A
106.1A
124.8A
124.8A
Power factor(@nominal power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Efficiency
Max. efficiency
98.8%
Euro-eta
98.5%
