11 S
p
e
c
i
f
i
c
a
t
i
o
n
1
1
.
1 MID
11-30K
TL3-XH series
11KTL3-XH
MID
12KTL3-XH
MID
MID
13KTL3-XH
15KTL3-XH
MID
Input data (DC)
Recommended Max. PV
power (for module STC)
22000W
24000W
26000W
30000W
Max. DC voltage
1100V
Startup voltage
200V
Full power voltage range
200V~850V
204V~850V
235V~850V
Nominal voltage
600V
MPPT voltage range
160-1000V
No. of MPPT trackers
2
No. of PV strings per
MPPT tracker
2/2
2/2
2/2
2/2
Max. input current per
MPPT tracker
32A/32A
32A/32A
32A/32A
32A/32A
Max. short-circuit
current per MPP tracker
40A
40A
Backfeed current to PV
array
0A
DC Battery
Compatible battery
(only)
APX HV Battery
(5kWh~60kWh)
Operating voltage range
600 V ~ 980 V
Max. operating current
25A/25A
Max. discharge power
11000W
12000W
13000W
15000W
Max. charge power
15000W/30000W
Output data (On-gird)
Nominal AC power
11000W
12000W
13000W
15000W
Max. AC apparent power
12100VA
13200VA
14300VA
16500VA
Nominal AC
voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Max. output current
18.3A
20A
21.7A
25A
AC inrush current
60A
Max. output fault current
74.1A
Model
Specifications
MID
11KTL3-XH
12KTL3-XH
MID
MID
13KTL3-XH
15KTL3-XH
MID
Max. output overcurrent
Protection
74.1A
Power factor(@nominal
power)
>0.99
THDi
<3%
AC grid connection type
3W+N+PE
Efficiency
Max. efficiency
98.0%
Euro-eta
97.50%
Output data (Backup)
Nominal output power
11000W
12000W
13000W
15000W
Max. apparent power
11000VA
12000VA
13000VA
15000VA
Max. output power of
single phase
3660W
4000W
4330W
5000W
Nominal AC output
voltage
230V/400V
Nominal AC output
frequency
50Hz
Max. output current
16.7A
18.2A
19.7A
22.7A
Power factor
0.8 leading to 0.8 lagging
THDv
THDv≤2%@Rload, THDv≤5%@RCDload
DCV
≤300mV AVG
Switch time
<500ms
Protection devices
DC reverse-polarity
protection
YES
DC switch
YES
DC surge protection
YES
Insulation resistance
monitoring
YES
AC surge protection
YES
AC short-circuit
protection
YES
Grid monitoring
YES
Anti-islanding
protection
YES
Model
Specifications
72
71
