Growatt MID 10-30KTL3-XH handleiding
Handleiding
Je bekijkt pagina 43 van 55
MID
11KTL3-XH
MID
12KTL3-XH
MID
13KTL3-XH
MID
15KTL3-XH
Residual-current
monitoring unit
YES
String fuse protection
NO
String monitoring
YES
AFCI protection
Configurable
General data
Dimensions (W / H / D)
in mm
579*433*217.5mm
Weight
29.5kg
Operating temperature
range
(>45°C Derating)
-25°C ... +60°C
Noise emission (typical)
≤36dB(A)
Altitude
4000m
Internal consumption at
night
<5.5W
Topology
Transformerless
Cooling
Natural heat dissipation
IP rating
IP66
Relative humidity
0~100%
DC connection
H4/MC4 (OPT)
AC connection
Waterproof PG connector + OT terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
Model
Specifications
17KTL3-XH
MID
MID
20KTL3-XH
MID
25KTL3-XH
MID
30KTL3-XH
Input data (DC)
Recommended Max. PV
power (for module STC)
34000W
40000W
50000W
60000W
Max. DC voltage
1100V
Start voltage
200V
Full power voltage range
266V~850V
313V~850V
261V~850V
313V~850V
Nominal voltage
600V
MPPT voltage range
160-1000V
No. of MPP trackers
2
3
No. of PV strings per
MPP tracker
2/2
2/2
2/2/2
2/2/2
Max. input current per
MPP tracker
32A/32A
32A/32A
32A/32A/32A
32A/32A/32A
Max. short-circuit
current per MPP tracker
40A
40A
Backfeed current to PV
array
0A
DC Battery
Compatible battery
(only)
APX HV Battery
(5kWh~60kWh)
Operating voltage range
600 V ~ 980 V
Max. operating current
25A/25A
Max. discharge power
17000W
20000W
25000W
30000W
Max. charge power
15000W/30000W
Output data (on-grid)
Nominal AC power
17000W
20000W
25000W
30000W
Max. AC apparent power
18700VA
22000VA
27500VA
30000VA
Nominal AC
voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Max. output current
28.3A
33.3A
41.6A
45.5A
AC inrush current
60A
Max. output fault current
74.1A
106.7A
Max. output overcurrent
Protection
74.1A
106.7A
Model
Specifications
7573
