2.6.8 GFCI (Ground Fault Circuit Interrupter)
The MID TL3-XH inverter is integrated with a leakage protection function. When the
leakage current exceeds 300mA and continues for more than 300ms, the inverter will
disconnect from the grid while reporting "Fault 201" and displaying "Residual I High".
This feature is designed to ensure the safety of users’ lives and property. The GFCI
function is enabled by default.
2.6.9 Parallel operation
The MID TL3-XH inverters can be connected in parallel to operate in the grid-tied
mode. In the parallel system, a ShineMaster-X or SEM-X from Growatt should be
installed to enable energy scheduling and the export limitation function. For detailed
instructions on how to use and configure this function, please see Section 5.11
Connecting inverters in parallel. To enable the parallel operation, the system should be
upgraded.
2.
6
.1
0 M
o
ni
t
o
rin
g
Th
e M
ID TL
3
-
XH inv
e
r
t
e
r h
as a rese
rv
e
d p
o
r
t f
or co
nn
ec
t
in
g t
o t
h
e da
t
a
l
o
g g
e
r. Af
t
e
r
in
s
t
a
llin
g a
n
d re
g
i
s
t
e
rin
g t
h
e G
r
o
w
a
t
t da
t
a
l
o
gg
e
r, y
ou ca
n m
o
ni
t
o
r t
h
e s
y
s
t
e
m
'
s
o
p
e
r
a
t
i
on s
t
a
t
us a
n
d co
nfi
g
u
r
e i
t
s fu
n
c
t
i
o
n
s o
n S
hin
e
Ph
o
n
e (
APP
)
, S
hin
e
S
e
rv
e
r
( )
, a
n
d t
h
e OS
S ( )
. h
tt
p
s
:
//
se
rv
e
r.
g
r
o
w
a
tt
.
co
m h
tt
p
s
:
//
o ss
.
g
r
o
w
a
tt
.
co
m
16
15
2.6.7 AFCI (Arc Fault Circuit Interrupter)
The AFCI function is disabled by default. You can enable this function on a couple of
platforms, including the OSS, ShineServer, ShinePhone and ShineTools. For details,
please see Section 8.6 AFCI. Alternatively, you can contact Growatt support for
assistance.
When the PV modules or the cables are in poor contact or damaged, an electrical arc
may occur on the DC side, which might lead to a fire hazard. Growatt inverters are
integrated with an arc-fault detection function in compliance with UL1699B-2018
standards. This feature is designed to ensure the safety of users’ lives and property.
Inspection upon delivery 3
3.1 Checking the packing list
Before unpacking the inverter, check the outer packing materials for any externally
visible damage. After unpacking the inverter, check the scope of delivery for
completeness. If the scope of delivery is incomplete or damaged, contact your dealer.
No.
Description
Quantity
A
Inverter
1
B
COM port connector
1
C
AC waterproof cover
1
D
AC waterproof connector
1
E
Quick Installation Guide
1
F
Wall-mounting bracket
1
G
Plastic expansion tube
5
H
Expansion screw
4
I
Hexagon head screw
2
J
PV connector
6/6
K
PV metal contact
6/6
L
PV terminal removal tool
1
Figure 3-1 Scope of delivery
Table 3-1 Packing list of the MID TL3-XH inverter
①
②
Installation
A B C D
E F G
H
I
K
J L
2.6.6 Dry contact
The MID TL3-XH inverter features the dry contact function. Once it is enabled, Pin 1
and Pin 2 of the COM port on the inverter will output a 12V signal when the inverter's
output power reaches the preset activation power level. This signal can be used as an
activation or deactivation signal for other devices. Conversely, when the inverter's
output power reaches the specified deactivation power level, the voltage output from
Pin 1 and Pin 2 of the inverter's COM port changes from 12V to 0V, providing another
signal that can be used as an activation or deactivation signal for other devices. To
configure this function, you can refer to section 8.3 Dry contact.
Note: MID-XH AU inverters have not been tested against multiple inverter combinations in
accordance with Section 5 of AS/NZS 4777.2:2020。
。
