2.6.3 OLED display
The MID TL3-XH inverter comes with an OLED screen to display critical information, as
shown in the figure below:
2.6.4 Export limitation
When the MID TL3-XH inverter is connected to an energy meter and the communication
between the inverter and the meter is established, the export limitation function can be
activated. The detailed configuring steps are shown in Section 8.1 Export limitation.
Ÿ When the “Phase levels” is disabled and the export limitation value is set to a positive
value, it indicates the power allowed to be exported to the grid as a percentage. For
example, if the inverter's rated power is 30 kW, and the export limitation is set to 10%,
the power allowed to be fed to the grid is 30 kW * 10% = 3 kW. If Phase L1 carries a 1
kW load, Phase L2 and Phase L3 do not carry a load, the output of the inverter would
be: L1: 1.33 kW, L2: 1.33 kW, L3: 1.33 kW and the power fed to the grid would be: L1:
0.33 kW, L2: 1.33 kW, L3: 1.33 kW.
Standard export limitation
Ÿ When the export limitation value is set to a negative value, it indicates the power
allowed to be drawn from the grid as a percentage. For example, if the inverter's rated
power is 30 kW, and the export limitation is set to -10%, the power allowed to be
drawn from the grid is 30 kW * 10% = 3 kW. If the load power is greater than 3kW (e.g.
load power is 4 kW), the power grid provides 3 kW, and other energy needed will be
supplied by the inverter output. When the combined PV and Battery energy is
insufficient (e.g. PV power + Battery power = 0.5 kW), the inverter will output at its
maximum power while drawing energy from the grid to power the loads.
13
14
Figure 2-8 OLED display (Only the ZBDC version is supported)
Ÿ When the export limitation value is set to a negative value, it indicates the power
allowed to be drawn from the grid as a percentage. For example, if the inverter's rated
power is 30 kW, and the export limitation is set to -10%, the power allowed to be
drawn from the grid is 30 kW * 10% = 3 kW. If the load power is greater than 3 kW (e.g.
load power is 4 kW), the power grid provides 3 kW, and other energy needed will be
supplied by the inverter output. When the combined PV and Battery energy is
insufficient (e.g. PV power + Battery power = 0.5 kW), the inverter will output at its
maximum power while drawing energy from the grid to power the loads.
Ÿ When the “Phase levels” is enabled and the export limitation value is set to a positive
value, it indicates the power allowed to be exported to the grid as a percentage. For
example, if the inverter's rated power is 30 kW, and the export limitation is set to 10%,
the power allowed to be fed to the grid is 30 kW * 10% = 3 kW. If Phase L1 carries a
1kW load, Phase L2 and Phase L3 do not carry a load, the output of the inverter would
be: L1: 2 kW, L2: 1 kW, L3: 1 kW and the power fed to the grid would be: L1: 1 kW, L2:
1 kW, L3: 1 kW.
Phase level export limitation
2.6.5 Demand Response Modes (DRMs) & Radio Ripple Control Receiver (RRCR)
Ÿ According to European standards, the MID inverter can be connected to a RRCR ,
which is enabled by default. For details, please refer to Section 8.2 DRMs & Remote
logic control.
The MID TL3-XH inverter is DRM compliant and can connect to a Radio Ripple Control
Receiver (RRCR). A 30-pin connector is used as the input port for DRMs and RRCR.
For the port definitions, you can refer to Section 5.7.1 COM port definition.
Ÿ In accordance with Australian standards, the MID inverter has been designed to
comply with Demand Response Modes (DRMs), with DRM 0 being a mandatory
requirement. The DRMs is set to disabled by default. To enable it, please contact
Growatt customer support. For details, please refer to Section 8.2 DRMs & Remote
logic control.
Ÿ Disabled by default, and can only be used when connected to the
APX battery.
NOTICE
OLED Structure
Status
Etoday
Etotal
Pm
AC R/ S/T
AC Freq/PF
BAT Info
PV Info
Setting
About
AC Info
Fault code
Status
BM Volt
Battery Power
Echarge-day
Edischarge-day
General Setting
Advanced
Setting
INV MODEL
INV Ver
BAT MODEL:
BAT Ver:
METER Ver:
Country/Area
ExportLimit
Language
Address
Power Sensor
PV1
PV2
INV SN
PV3
Grid Charge
EPS Info
EPS R/S/T
EPS Freq
Per Load
Password
Backup Setting
WideVolt Set
System Mode
DRMS
Enable NLine
ResetFactory
