2.5.4 Backup mode
Ÿ The MID TL3-XH inverters support the Backup function. To enable
this feature, you need to purchase the SYN BOX (SYN 100-XH-30)
and a compatible battery system (APX 98034-P2). Refer to section
8.5 Backup function (Optional) for instructions on enabling this
function.
NOTICE
The Backup mode is mainly designed for scenarios with an unstable grid and critical
loads. In the event of a grid anomaly or outage, the inverter switches to the off-grid
mode (default values: 230/400V, 50Hz) to supply power to critical loads. When the grid
power is restored, the inverter switches back to the grid-tied mode.
2.5.4.1 The maximum off-grid power and recommended battery configuration
Ÿ A maximum of 2 battery systems (APX 98034-P2) can be
connected to each inverter, and the BMS (battery management
system) supports up to 6 battery modules (APX 5.0P-B1).
Ÿ RCD load: total power ≤ 0.58× rated output power of the inverter.
Ÿ The maximum off-grid output power is determined by several
factors, including the power of the battery system and the
inverter’s power rating. The power of each battery module is
2.5kW. Please choose the appropriate battery configuration to
meet your power needs.
Information
The table below illustrates the relationship between the maximum off-grid output
power, the number of battery modules (BM) and the inverter power rating.
APX 5.0P-B1
1
2
3
4
5
6
MID 10KTL3-XH
2.5kW
5kW
7.5kW
10kW
10kW
10kW
MID 11KTL3-XH
2.5kW
5kW
7.5kW
10kW
11kW
11kW
MID 12KTL3-XH
2.5kW
5kW
7.5kW
10kW
12kW
12kW
MID 13KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
13kW
MID 15KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
15kW
MID 17KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
15kW
MID 20KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
15kW
MID 25KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
15kW
MID 30KTL3-XH
2.5kW
5kW
7.5kW
10kW
12.5kW
15kW
No.of BM
Output power
Model
APX 5.0P-B1
7
8
9
10
11
12
MID 10KTL3-XH
10kW
10kW
10kW
10kW
10kW
MID 11KTL3-XH
11kW
11kW
11kW
11kW
11kW
11kW
MID 12KTL3-XH
12kW
12kW
12kW
12kW
12kW
12kW
MID 13KTL3-XH
13kW
13kW
13kW
13kW
13kW
13kW
MID 15KTL3-XH
15kW
15kW
15kW
15kW
15kW
15kW
MID 17KTL3-XH
17kW
17kW
17kW
17kW
17kW
17kW
MID 20KTL3-XH
17.5kW
20kW
20kW
20kW
20kW
20kW
MID 25KTL3-XH
17.5kW
20kW
22.5kW
25kW
25kW
25kW
MID 30KTL3-XH
17.5kW
20kW
22.5kW
25kW
27.5kW
30kW
No.of BM
Output power
Model
1211
Table 2-3 Relationship between the Max. off-grid output power, the number of BM and
the inverter rating
2.6 Functions
2.6.1 Touch button
The MID TL3-XH inverter features a touch button for user interaction. Tapping the
button allows you to view different contents displayed on the OLED screen. Configuring
parameters on the OLED display is also supported. For details, please refer to Section
6 Human-machine interaction.
2.6.2 LED indicator
The MID TL3-XH inverter is equipped with a leaf-shaped LED indicator, which
demonstrates the operating status of the inverter. The meaning of the LED indication is
illustrated in the table below:
Symbol
Description
Inverter status
LED color
LED status
Inverter status
indicator
Standby
Green
0.5s on and 2s
off
Normal
Green
Solid
Fault
Red
Solid
Inverter
warning/Batter
y fault
Green
0.5s on, 0.5s
off/0.5s on, 2s
off
Programming
Yellow
1s on and 1s off
Table 2-4 LED indicator description
