7
CAUTION: When using a key chuck designed for cylindrical drills, do
not work with a hammer drill. Using it will lead to very rapid damage to
the key drill chuck and the SDS+ chuck on the hammer drill.
Modes of operation
The hammer drill has two mode dials fig. C.
After the individual operating modes, set the dial to the following positions:
1. Drilling without impact Fig. C1
2. Drilling with impact Figure C2
3. Positioning the flat chisel in the optimum position fig. C3
4. Chiselling/forging Fig. C4
MAINTENANCE AND STORAGE
Pull the mains plug before any maintenance work on the unit.
To ensure safe and correct working, always keep the machine and the
ventilation slots clean. Clean the tool holder after each working day.
Replacing the dust cover
Damaged dust protection caps should be replaced, as dust that gets into
the tool holder can cause it to fail.
If a machine malfunctions despite the care taken in production and testing,
the repair should be carried out by an authorised qualified service.
KIT CONTENTS:
• Hammer drill
• SDS+ drill bit
• Drill depth limiter
• Drill chuck with key
• Technical documentation
• Transport case
Rated data
Supply voltage
230 V AC
Supply frequency
50 Hz
Rated power
900 W
No-load speed
0 - 950 min
-1
Impact frequency
0 - 5300 min
-1
Impact energy
3.4 J
Maximum drilling diameter in:
Concrete
30 mm
Wood
30 mm
Steel
13 mm
Tool holder type
SDS Plus
IP degree of protection
IPX0
Protection class
II
Mass
3.45 kg
Year of production
2023
58G539 stands for both type and machine designation
NOISE AND VIBRATION DATA
Sound pressure level
LpA = 91.2 dB (A) K=3dB (A)
Sound power level
LWA = 102.2 dB (A) K=3dB (A)
Vibration acceleration values
Percussion drilling in
concrete
Chisel mode
ah = 17.2 m/s
2
K=1.5 m/s
2
ah = 14.8 m/s
2
K=1.5 m/s
2
Information on noise and vibration
The noise emission level of the equipment is described by: the emitted
sound pressure level LpA and the sound power level LWA (where K denotes
measurement uncertainty). The vibration emitted by the equipment is
described by the vibration acceleration value ah (where K is the
measurement uncertainty).
The emitted sound pressure level LpA , the sound power level LWA and the
vibration acceleration value ah given in this manual have been measured
in accordance with IEC 62841-2-6. The vibration level ah given can be
used to compare equipment and to make a preliminary assessment of
vibration exposure.
The vibration level quoted is only representative of the basic use of the
unit. If the unit is used for other applications or with other work tools, the
vibration level may change. A higher vibration level will be influenced by
insufficient or too infrequent maintenance of the unit. The reasons given
above may result in increased vibration exposure during the entire working
period.
In order to accurately estimate vibration exposure, it is necessary to
take into account periods when the unit is switched off or when it is
switched on but not used for work. Once all factors have been
accurately estimated, the total vibration exposure may turn out to be
much lower.
In order to protect the user from the effects of vibration, additional safety
measures should be implemented, such as cyclical maintenance of the
machine and working tools, securing an adequate hand temperature and
proper work organisation.
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with household
waste, but should be taken to appropriate facilities for disposal. Contact
your product dealer or local authority for information on disposal. Waste
electrical and electronic equipment contains environmentally inert
substances. Equipment that is not recycled poses a potential risk to the
environment and human health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including, among
others. Its text, photographs, diagrams, drawings, as well as its composition, belong
exclusively to Grupa Topex and are subject to legal protection under the Act of 4 February
1994 on Copyright and Related Rights (ie Journal of Laws 2006 No. 90 Poz. 631, as
amended). Copying, processing, publishing, modification for commercial purposes of the
entire Manual and its individual elements, without the consent of Grupa Topex expressed
in writing, is strictly prohibited and may result in civil and criminal liability.
EC Declaration of Conformity
Manufacturer: Grupa Topex Sp. z o.o. Sp.k., Pograniczna 2/4 02-285
Warszawa
Product: SDS+ hammer drill
Model: 58G539
Trade name: GRAPHITE
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
The product described above complies with the following documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And meets the requirements of the standards:
EN 62841-1:2015; EN IEC 62841-2-6:2020+A11; EN ISO 12100:2010;
EN IEC 55014-1:2021; EN IEC 55014-2:2021; EN IEC 61000-3-
2:2019+A1; EN 61000-3-3:2013+A1+A2;
EN IEC 63000:2018
This declaration relates only to the machinery as placed on the market
and does not include components
added by the end user or carried out by him/her subsequently.
Name and address of the EU resident person authorised to prepare the
technical dossier:
Signed on behalf of:
Grupa Topex Sp. z o.o. Sp.k.
2/4 Pograniczna Street
02-285 Warsaw
Paweł Kowalski
TOPEX GROUP Quality Officer
Warsaw, 2022-08-30
DE
ÜBERSETZUNG (BENUTZERHANDBUCH)
Bohrhammer: 58G539
HINWEIS: BEVOR SIE DAS GERÄT BENUTZEN, LESEN SIE BITTE
DIESE ANLEITUNG SORGFÄLTIG DURCH UND BEWAHREN SIE SIE
ZUM NACHSCHLAGEN AUF. PERSONEN, DIE DIE ANLEITUNG
NICHT GELESEN HABEN, DÜRFEN DAS GERÄT NICHT
ZUSAMMENBAUEN, EINSTELLEN ODER BEDIENEN.
BESONDERE SICHERHEITSBESTIMMUNGEN
HINWEIS!
Lesen Sie die Bedienungsanleitung sorgfältig durch, beachten Sie die
darin enthaltenen Warnhinweise und Sicherheitsvorschriften. Das Gerät
wurde für einen sicheren Betrieb konzipiert. Dennoch: Installation,
Wartung und Betrieb des Geräts können gefährlich sein. Wenn Sie die
folgenden Verfahren befolgen, verringern Sie die Gefahr von Bränden,
Stromschlägen und Verletzungen und verkürzen die Installationszeit des
Geräts
SICHERHEITSVORSCHRIFTEN
WARNHINWEISE ZUR ARBEIT MIT EINEM ELEKTROHAMMER
Hinweis: Bevor Sie mit der Einstellung fortfahren,
Wartung oder Reparatur, ziehen Sie das Netzkabel aus dem
Netzsteckdose.
