06 Electrical Connection
User Manual V1.2-2024-10-30
3
AC Output Cable
(GRID)
Single-core
or Multi-core
Outdoor Copper-
core Cable or
Aluminum Cable
ETC/BTC 50K series：
• Single core cable outer diameter: 8-11mm
• Multi-core cable outer diameter: 30-39mm
• Copper Cable Conductor Cross Sectional Area(S):
35mm
2
≤S≤70 mm
2
;
• Aluminum Cable Conductor Cross Sectional
Area: 50mm
2
≤S≤95 mm
2
• ETC/BTC 100K series：
• Single core cable outer diameter: 9-11mm
• Multi-core cable outer diameter: 33-39mm
• Copper Cable Conductor Cross Sectional Area(S):
50mm
2
≤S≤70 mm
2
;
• Aluminum Cable Conductor Cross Sectional
Area: 70mm
2
≤S≤95 mm
2
4
AC Output Cable
(LOAD)
Single-core
or Multi-core
Outdoor Copper-
core Cable or
Aluminum Cable
ETC/BTC 50K series：
• Single core cable outer diameter: 8-11mm
• Multi-core cable outer diameter: 30-39mm
• Copper Cable Conductor Cross Sectional Area(S):
35mm
2
≤S≤70 mm
2
;
• Aluminum Cable Conductor Cross Sectional
Area: 50mm
2
≤S≤95 mm
2
ETC/BTC 100K series：
• Single core cable outer diameter: 9-11mm
• Multi-core cable outer diameter: 33-39mm
• Copper Cable Conductor Cross Sectional Area(S):
50mm
2
≤S≤70 mm
2
;
• Aluminum Cable Conductor Cross Sectional
Area: 70mm
2
≤S≤95 mm
2
5
RS485, remote
shutdown,
DRED, RCR
ommunication
Cable
Outdoor Shielded
Twisted Pair
Conductor Cross Sectional Area: 0.25 mm
2
- 1 mm
2
CAN
communication
Cable for
inverter
Paralleling
Straight-through
Ethernet cable*
1
-
Note:
*1: please use one set of the twisted pairs.
[1] A copper to aluminum wiring terminal is required when using an aluminum cable.
[2] Cable length of the RS485 communication cable: ≤1000m.
The values in this table are valid only if the external protective earthing conductor and the
phase conductors are the same material. Otherwise, the cross-sectional area of the external
protective earthing conductor is to be determined in a manner which produces a conductance
equivalent to that which results from the application of this table.
