28
06 Electrical Connection
User Manual V1.2-2024-10-30
6 Electrical Connection
6�1 Safety Precaution
NOTICE
• Wear personal protective equipment like safety shoes, safety gloves, and insulating gloves
during electrical connections.
• All electrical connections should be performed by qualied professionals.
• Cable colors in this document are for reference only. The cable specications shall meet local
laws and regulations.
DANGER
• Perform electrical connections in compliance with local laws and regulations. Including
operations, cables, and component specications.
• Disconnect the DC switch, AC output switch, and battery switch of the inverter to power o
the inverter before any electrical connections. Do not work with power on. Otherwise, an
electric shock may occur.
• Tie the cables of the same type together, and place cables of dierent types apart. Do not
place the cables entangled or crossed.
• If the tension is too large, the cable may be poorly connected. Reserve a certain length of the
cable before connecting it to the inverter cable port.
• Make sure that the cable conductor is in full contact with the terminal and the cable insulation
part is not crimped with the terminal when crimping the terminal. Otherwise, the inverter
may not be able to work properly, or the connection may be unreliable during working,
which may cause terminal block damage, etc.
Cable requirements:
No� Type
Specication
1
DC Input Cable
(MPPT)
DC Power Cable
(BATTERY)
Single-core
Outdoor Copper-
core Cable or
Aluminum Cable
Copper Cable Conductor Cross Sectional Area:
35mm
2
≤S≤70mm
2
Aluminum Cable Conductor Cross Sectional Area:
50mm
2
≤S≤95 mm
2
2 PE Cable
Single-core
Outdoor Copper-
core Cable
Conductor cross sectional area S
PE
≥ S/2
