16
03 Product Introduction
User Manual V1.2-2024-10-30
3�3�2 Inverter operation mode
No� Parts Description
1 Waiting
mode
Waiting stage after the inverter is powered on.
• When the conditions are met, it enters the self-check mode.
• If there is a fault, the inverter enters the Fault mode.
• If there is an update request, the inverter enters the Updating mode.
2 Self-check
mode
Before the inverter starts up, it continuously performs self-check,
initialization, etc.
• When the conditions are met, it enters the Grid-tied mode, and the
inverter starts the on grid connection.
• If the grid is not detected, it enters the O-grid mode and the inverter
runs o-grid; if the inverter has no o-grid function, it enters the Wait
mode.
• If the self-check is not passed, it enters the Fault mode.
• If there is an update request, the inverter enters the Updating mode.
3 Grid-Tied
mode
The inverter is successfully connected to the grid.
• If the grid is not detected, it enters the O-grid mode.
• If a fault is detected, it enters the Fault mode.
• If the conditions do not meet the requirements for grid connection, and
the o-grid output function is not turned on, it enters the Wait mode.
• If there is an update request, the inverter enters the Updating mode.
Waiting mode
Self-check mode
O-grid mode
Grid-Tied mode
Upgrade modeFault mode
