P11
FIGURE 7
FIGURE 8
● Two people should grab the four corners of the Galaxy Plus, lift and car it veically, and
then adhere the Galaxy Plus face-up to the colour steel tile. The end of the structural adhesive
should be indented by 5mm compared to the long edge of the product (Figure 8).
● Use soft tools to gently press the front side of the product, making the Galaxy Plus bonded
to the rib of the colour steel tile roof rmly, with a glue thickness of 2~3mm.
● Repeat the above steps and complete the installation of the remaining products.
5mm
Galaxy Plus
