08 System Commissioning
50
User Manual V1.2-2025-04-15
Add other devices
Parameter Description
Device Name Dene the device name based on actual needs.
Device Type Select Other Devices.
Communication
Protocol
Select based on the communication protocol of the device. Support
Modbus-RTU, Modbus-TCP and GW-XPH.
When the Communication Protocol is Modbus-RTU, set the following parameters based
on actual situation:
Communication Port
Select the actual connected port on the EzLogger. Supported port:
RS485-1, RS485-2, RS485-3, RS485-4.
Device Subtype
Select the device type based on the actual situation. Supported: Weath-
er Station, MV Station or Other.
MV Station Sub-Type
If the Device Subtype is MV Station, set the MV Station Sub-Type to
General or Distributed.
Terminal Address
Device address. Set the parameter based on the actual power plant
planning.
Protocol Type Set the protocol type based on the actual situation.
Access Point Table Import the access point table of the connected device.
IEC104 Forwarding Select the forwarding table based on actual situation.
Modbus-TCP For-
warding
Select the forwarding table based on actual situation.
Parameter Description
Meter Purpose
• Select based on the actual purpose. Supported: Grid Side Meter or
Point Of Interconnection Meter
• Grid Side Meter: for power limiting, supports Goodwe Meter(GM330),
UMG604PRO and Acrel-DTSD1352.
• Point Of Interconnection Meter: for metering, supports Schnei-
der-IEM3255.
• When several smart meters are connected in the system for backow
prevention, set all backow prevention meters as grid side meters.
Terminal Address
Device address. Set the parameter based on the actual power plant
planning. Select Auto Generate when there is no need to set the param-
eters based on the actual settings.
Access Point Table Select the point table based on actual situation.
