22 MAD MAXX Quick Start and Safety Manual
2. Remove the rubber connector seal from the powerCON TRUE1 TOP MAINS IN
socket (arrowed in Figure 6). Line up the keys in the connector correctly with the
keyways in the socket.
3. Insert the connector into the socket. Do not use force. If you feel any more than
light resistance when you try to push the connector into the socket, something is
wrong – you may have lined up keys and keyways incorrectly. Remove the
connector and check the positions of keys and keyways before trying to insert the
connector again.
4. Twist the connector fully clockwise to lock. Listen for a ‘click’ that indicates that
the connector is locked.
5. Release the pan and tilt locks, check the clearance around the head and make
sure that nobody is looking directly at the fixture. Then apply power to the power
input cable.
Installing power connectors on the input cable
It is possible to install a cord cap / mains power plug that is suitable for your local
convenience receptacles / power sockets on the supplied power input cable. If you
do this, check that the cord cap / plug is rated minimum 250 V, 16 A, that it has a
connection to ground / earth and that it has an integral cable grip. Follow the cord
cap / plug manufacturer’s assembly instructions.
If you need to install a Neutrik powerCON TRUE1 TOP connector on a power cable,
follow the instructions given on the Neutrik website at www.neutrik.com.
Respect the color coding used in the supplied power cable and in your local mains
power wiring system. US and EU systems use the color coding shown below:
Live or L
Neutral or N
Ground / Earth or
US system
Black
White
Green
EU system
Brown or
black
Blue
Yellow/green
Connecting to control data
The fixture can be controlled via USITT512 DMX over a standard DMX cable link or via
other control protocols over an Ethernet link. The fixture’s Protocol Setup control
menu lets you set the fixture’s control protocol (see the fixture’s User Manual
available online at www.glp.de for details).
If you would like advice with planning and installing a suitable control link, your GLP
supplier will be happy to provide assistance.
DMX link
See ‘Fixture overview’ on page 15. The fixture has IP65-rated Neutrik TOP 5-pin XLR IN
and THRU sockets for connection to a DMX cable link. Connectors use standard DMX
pinout:
● Pin 1 = Ground
