German Light Products
®
Rev. 20240618-01 21
Pixel Mirror
Off
Normal pixel order: 1 to 10
(Pixel 1 is at Power IN)
x-mirror
Reversed pixel order: 10 to 1
(Pixel 1 is at Power OUT)
y-mirror
Inverted pixel order
(Pixel 11 to 20 on top row)
x-y-mirror
Reversed and inverted pixel order
(Pixel 20 to 11 on top row)
Background
Crossfade
Crossfading from background
color to main color
Mix
Main color mixes with background
color
Override
Main color completely overrides
background color
No Signal
Blackout
If DMX signal absent, fixture blacks
out
Hold
If DMX signal absent, fixture holds
last DMX values received
Houselight
If DMX signal absent, fixture goes to
constant white light
Fan Mode
Regulated
Fan speed regulated
High
Fans run at constant high speed,
output reduced if necessary
Medium
Fans run at constant medium
speed, output reduced if
necessary
Low
Fans run at constant low speed,
output reduced if necessary
PWM Frequency
2700 Hz
Sets LED refresh rate
3000 Hz
4800 Hz
9600 Hz
Display Mode
Auto
Control panel display enters sleep
mode after short period. An error
will cause the display to light up.
On
Display constantly on
Off
Display constantly off. An error will
not cause the display to light up.
Display Orientation
Auto
Control panel display
automatically inverts if fixture is
inverted
Normal
Display normal
Inverted
Display inverted down to up
Load Settings
Preset 1
Hold 3 sec.
Loads custom settings and custom
offsets
Preset 2
Hold 3 sec.
Preset 3
Hold 3 sec.
Default
Hold 3 sec.
Loads factory default settings and
offsets
Information
Show Errorlist
Shows last and current errors
Show Serial Number
Shows fixture’s serial number
Show SW version
Shows current software version
Show device info
Shows fixture information
Show device hours
Shows resettable and non-
resettable counters
