22 JDC Line 500 User Manual
Device Power Cycles
Shows resettable and non-
resettable power cycle counters
Show DMX Input
Shows DMX values received for all
functions
Show Signal Quality
Shows signal quality (framerate,
noise, etc.)
Show Temperature
Shows temperatures in °C & °F
Show Fan Monitor
Shows fan rpm and Voltage
Manual Control
Reboot (confirm 3 sec.)
Reboots fixture
Manual DMX
Intensity coarse
(RGBW)
000 - 255
Manual fixture control
Intensity fine (RGBW)
000 - 255
Duration (RGBW)
000 - 255
Rate (Shutter)
(RGBW)
000 - 255
Intensity Effects
[Strobe Mode]
(RGBW)
000 - 255
CTC
000 - 255
R
000 - 255
G
000 - 255
B
000 - 255
W
000 - 255
Capture DMX values (confirm 3 sec.)
Takes a snapshot of DMX values
currently being received and uses
them as manual DMX values
Reset Manual values (confirm 3 sec.)
Resets all manual DMX values to
default
Service
Test All
Confirm
Runs continuous test sequence:
pan & tilt first, then all FX with head
straight up. Stop test by pressing
"Back" button.
Test White
Confirm
Runs continuous test sequence on
White LEDs. Stop test by pressing
"Back" button.
Test RGB
Confirm
Runs continuous test sequence on
RGB LEDs. Stop test by pressing
"Back" button.
Advanced
(Press and
hold Enter for
3 sec. to
confirm)
Reset Counters
Device Hours (confirm 3
sec.)
Returns resettable counter to zero
Device Power Cycles
(confirm 3 sec.)
Max Temperatures
(confirm 3 sec.)
Save Settings
Preset 1 (confirm 3 sec.)
Saves all custom settings including
offsets as a preset
Preset 2 (confirm 3 sec.)
Preset 3 (confirm 3 sec.)
Load factory backup (confirm 5 sec.)
Loads factory default settings,
resets custom offsets, deletes
custom presets, sets resettable
counters to zero, sets DMX address
to 1, sets DMX mode to default
(Mode 2: WStrobe + RGBStrobe)
Default settings are written in BOLD type.
