German Light Products
®
Rev. 20240618-01 29
Control / Settings channel applies to
both Strobe A and Strobe B.
RGB segments individual control
adjusts the color of the individual RGB
segments on each Strobe. The output
of these segments is determined by the
Strobe A and Strobe B RGB segments
overall control channels (see above).
The upper and lower halves of each
segment are controlled together,
giving 20 RGB pixels on Strobe A and 20
RGB pixels on Strobe B.
Control / Settings lets you configure the
fixture remotely via DMX. Settings that
you configure on the Control / Settings
channel apply to both Strobe A and
Strobe B.
Strobe B RGB segments overall control
97
Intensity coarse
98
Intensity fine
99
Duration
100
Flash rate (Shutter)
101
Intensity effects (Strobe mode)
102
CTC
103
Strobe phase
Strobe B Background color
104
Intensity background
105
Red background
106
Green background
107
Blue background
108
White background
Strobe B RGB segments individual control
109
Red segment 01
110
Green segment 01
111
Blue segment 01
…
…
166
Red segment 20
167
Green segment 20
168
Blue segment 20
