28 JDC Line 1000 DMX Channel Index
DMX Mode 3: W Strobe + RGB Pixel
168 DMX Channels
White strobe with FX runs on the White
segments only of each Strobe. Each
Strobe has its own effects engine with
50 patterns. Crossfading sets the
duration of changes between the
steps in each pattern. Transition sets
the duration of changes from one
pattern to the next.
Pattern chain length lets you set up a
chain of fixtures for the pattern to run
across in a chase by defining the total
number of fixtures in the chain. Pattern
chain position lets you set which
position in the chain the fixture will
occupy: first, second or third etc. fixture
in the chain. The JDC Line 1000
occupies two positions as if it was two
JDC Line 500s.
RGB segments overall control gives
overall output control of each Strobe’s
individually controllable RGB segments
(see below). It offers the standard
strobe channels for intensity and strobe
effects plus a CTC Channel which lets
you adjust the color temperature of
the white output.
Strobe phase lets you shift the timing of
each RGB Strobe (A or B) by 1 – 359°
relative to the corresponding White
Strobe (A or B). A 180° shift will result in
a flip-flop between white and RGB
flashes.
Background color sets a background
color on the RGB segments on the RGB
segments for each Strobe. As standard,
the main color output always has
higher priority than the background
color. You can define how
background color and main color are
mixed using Background color on DMX
channel 6, the Control/Settings
channel. The setting selected on the
Mode 3
W Strobe + RGB Pixel
Strobe A White strobe with FX
1
Intensity coarse
2
Intensity fine
3
Duration
4
Flash rate (Shutter)
5
Intensity effects (Strobe mode)
6
Control / Settings
7
Pattern select
8
Pattern step / speed
9
Pattern step crossfade
10
Pattern transition
11
Pattern chain length
12
Pattern chain position
Strobe A RGB segments overall control
13
Intensity coarse
14
Intensity fine
15
Duration
16
Flash rate (Shutter)
17
Intensity effects (Strobe mode)
18
CTC
19
Strobe phase
Strobe A Background color
20
Intensity background
21
Red background
22
Green background
23
Blue background
24
White background
Strobe A RGB segments individual control
25
Red segment 01
26
Green segment 01
27
Blue segment 01
…
…
82
Red segment 20
83
Green segment 20
84
Blue segment 20
Strobe B White strobe with FX
85
Intensity coarse
86
Intensity fine
87
Duration
88
Flash rate (Shutter)
89
Intensity effects (Strobe mode)
90
No function
91
Pattern select
92
Pattern step / speed
93
Pattern step crossfade
94
Pattern transition
95
Pattern chain length
96
Pattern chain position
