12 Revision 20240618-01
● Off gives normal pixel layout (see Figure 3). Pixel 01 is at the Power OUT/THRU end of
the fixture, on the left when facing the fixture with the fixture oriented normally. This is
the default pixel layout setting.
RGB
Upper
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
White
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
RGB
Lower
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Figure 3. Normal pixel layout in Section A (identical in Section B)
● X-mirror reverses the order of the pixels so that they run from right to left. In this
configuration, Pixel 01 is at the Power IN end of the fixture, on the right when facing
the fixture with the fixture oriented normally.
● Y-mirror inverts the RGB pixel rows so that the pixels run from left to right but pixels 11
to 20 move to the top row and pixels 1 to 10 move to the bottom row of the fixture.
Top and bottom are relative to the control panel display when the display
orientation is set to Normal.
● X-Y-mirror reverses the order of the pixels and inverts the RGB pixel rows at the same
time.
You can change the Pixel mirror setting on the Control / Settings DMX channel, in the
Fixture Settings menu in the fixture’s control panel.
No-signal behavior
You can decide how the fixture should behave if it is not receiving a DMX signal (if the
fixture is being controlled by DMX but the DMX signal stops, or if you apply power to
the fixture when no DMX signal is present). Three options are available:
● Blackout – The fixture goes to dead blackout. This is the default setting.
● Hold – The fixture holds the last DMX values that it received.
● Houselight – The fixture switches to the maximum light level that can be displayed
continuously.
These settings are available on the Control / Settings DMX channel, in the Fixture
Settings menu in the fixture’s control panel, or via RDM.
To avoid any possibility of unexpected behavior from a powerful strobe light if the DMX
signal fails, we recommend that you always set the fixture to Blackout or Houselight.
Fan Mode
The Fan Mode setting gives different options for the fixture’s cooling fan operation and
temperature management. Having options to choose from can be very helpful if you
are operating the fixture in a very hot or noise-sensitive environment. Four options are
available:
