German Light Products®
JDC Line 1000 User Manual 11
Rate
If no intensity effect is selected, the Flash Rate channel lets you adjust the interval
between flashes:
● At DMX values from 000 to 004 the fixture will not flash.
● At DMX values from 251 to 255 the fixture will execute a continuous on.
● At DMX values from 005 to 250 the fixture will perform flashes with long intervals to
super-short intervals between flashes.
If an intensity effect is selected, the Flash Rate channel lets you adjust the speed of the
intensity effect.
Flash style
The JDC Line 1000 offers two types of LED behavior when operating as a strobe:
● Normal sets LEDs to light continuously during flashes at the PWM rate set using the
control panel (the default rate is 3000 Hz). This is the default flash style setting.
● Xenon sets LEDs to mimic the high-frequency flicker during flashes that is
characteristic of xenon tube strobe lights.
You can change the Flash style setting in the Fixture Settings menu in the fixture’s
control panel, on the Control / Settings DMX channel, or via RDM.
White point
This setting lets you select the white point obtained when RGB is set to 100% and obtain
a clean white light with fixed white point when opening the fixture’s shutter without
adjusting RGB color or programming color presets. The following color temperatures
are available as fixed white points: 8000 K, 6500 K and 5600 K. The default setting is
6500 K.
Setting White point to Off disables this feature and puts RGB control into raw mode.
You can change the White point setting in the Fixture Settings menu in the fixture’s
control panel, on the Control / Settings DMX channel, or via RDM.
CTC
Using the CTC (Color Temperature Correction) channel lets you temporarily leave the
fixed white point of the fixture and change it within a color temperature range of 10
000 K to 2 500 K.
Note that RGB needs to be set to 100% to mix pure white. Decreasing RGB values will
modify the color relative to the chosen CTC white point.
Pixel mirror
To achieve symmetrical effects in multiple installations or co-ordinate effects when
fixtures are not oriented identically, the JDC Line 1000 lets you quickly reverse and/or
invert the order of the pixels in each section, A and B:
