GLP JDC Line 1000 handleiding
Handleiding
Je bekijkt pagina 10 van 72
www.glp.de
10 Revision 20240618-01
Override – the Background Color stays in the background. The color displayed
using the main channels has higher priority and will not mix with the background
color. As soon the main color value is >0 the background color will black out and
the main color will appear. For example, if you set a blue background color and
then fade in continuous red on the main color channels, the blue will disappear
completely and the red will fade up from zero intensity. The main red color will not
mix or crossfade with the background blue color.
You can select the Crossfade, Mix or Override options in the Fixture Settings menu in
the fixture’s control panel, on the Control / Settings DMX channel, or via RDM.
Dimming
The Dimmer channels control the output of the fixture in 16-bit resolution. You can
select from Linear or Soft dimming curves in the Fixture Settings menu in the fixture’s
control panel, on the Control / Settings DMX channel, or via RDM.
See Figure 2. The dimming curve options available are:
● Linear - the Linear setting gives a dimming curve that the eye perceives as linear.
Intensity appears to increase and decrease evenly throughout the dimming range.
● Soft - The Soft (square law) setting gives finer control at lower light levels, where the
eye is most sensitive to changes in light intensity, and coarser control at higher light
levels. This is the default dimming curve setting.
Duration
The Flash Duration channel lets you adjust the length of flashes from super-short to long.
You can change the Duration style setting in the Fixture Settings menu in the fixture’s
control panel, on the Control / Settings DMX channel, or via RDM. Two different types
of flash duration control are available:
● Normal control lets you vary the duration from short to long independently of the
Flash Rate channel setting. This is the default flash duration setting.
● Percentage control lets you vary the duration as a percentage of the selected Flash
Rate.
Figure 2. Dimming curves
