www.glp.de X5 IP
12 impression X5 IP User Manual
color presets are always mixed with the best available spectrum. Color filter color
coordinates are based on a Source C (daylight) light source.
Besides static color presets, the color wheel channel also offers continuous color
scrolling through the colors of the spectrum. When set to Rainbow Scroll the fixture
runs through a rainbow sequence of colors with color crossfading speed variable
from slow to fast.
If a color coordinate is outside the possible color gamut of the light source, the
fixture tries to match the target color as closely as possible.
Note: Color wheel color presets have higher priority than the Color Mix, CTO and
M/G Shift channels.
The virtual color wheel channel must be set to DMX 000 in order to use normal
RGB, RGBL or x:y color mixing.
Tungsten simulation
The tungsten filament simulation channel allows the user to select between
different tungsten options in all three Color Mix modes.
The first part of the Tungsten channel offers standard tungsten features with fixed
color temperature, red shift and delayed intensity changes. The color temperature,
the color shift and the inertia of the selected tungsten filament light source are fully
simulated. The value set on the Tungsten channel has higher priority than the color
wheel or CTC.
The second part of the Tungsten channel lets you apply one of the tungsten effects
(inertia and intensity) to the currently mixed color or the currently selected color
temperature on the CTC channel.
Note: The Tungsten simulation channel affects the entire fixture. Setting the
Tungsten channel to a specific value will affect the output of the Main module and
Sub module.
Shutter
The fixture’s shutter channel offers continuous blackout, continuous open and a
range of intensity effects.
Depending on the selected Sub Module Mode, the shutter channel of the Main
module channel group acts as either a master shutter or as the shutter channel of
the Main module independently of the Sub module.
The following shutter effects are available:
● Single flash performs exactly one single flash with each value change within this
DMX value slot.
● Pulse slow → fast varies intensity up and down smoothly with the same fade-in
and fade-out times. Speed can be adjusted from slow to fast.
● Pulse opening fades in and then snaps to blackout. Speed can be adjusted from
slow to fast.
● Pulse closing fades out and then snaps to full. Speed can be adjusted from slow
to fast.
