German Light Products®
Rev. 20250116-02 13
4. Control panel
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and backlit graphic LCD display with self-charging battery
allow you to change fixture settings, view readouts and use utilities quickly and
intuitively, even when the fixture is disconnected from power.
To allow comfortable use of the control panel on the side arm of the yoke, pan/tilt is
automatically disabled for a few seconds if you press any button on the control panel
and remains disabled for as long you are working in the control panel. If no button is
pressed for a few seconds, head movement is re-enabled with pan and tilt correction
applied.
Default information screen
When power is applied, the fixture performs a reset. After the reset has completed, the
default information screen appears in the control panel display on the side of the yoke.
At any other time, you can press any key to unlock the control panel. Doing this also
calls up the default information screen in the control panel display.
See Figure 3. The top line of the default information screen shows:
● Main CPU firmware version
● DMX Mode
The center of the screen shows the following information:
Figure 3. Default information screen
0.4.3/D/M1
DMX
001
(1…35)
