14 impression® FR1 User Manual
Blackout sets the fixture to black out whenever it is not receiving a DMX signal.
Stand-Alone sets the fixture to play its stored stand-alone scene (see DMX Shot below)
when the fixture is not receiving a DMX signal. If no stand-alone scene is stored in
memory, the fixture will black out.
DMX Shot takes a snapshot of the DMX values that are currently being received and
stores them in the fixture’s memory as its stand-alone scene. The fixture will display this
stand-alone scene if it is set to Stand-Alone (see above) and is not receiving a DMX
signal.
You can select one of the above four settings using the control panel or the
Control/Settings DMX channel.
Zoom
The impression FR1 has a 10:1 zoom range. You can narrow the beam angle from 35° in
flood mode to 3.7° in spot mode.
Zoom can be inverted from flood spot to spot flood using the control panel and
the Control/Settings DMX channel. The default setting for zoom inversion is OFF.
Control panel
The control panel on the side of the yoke has a backlit graphic LCD display for setting
up the fixture and changing fixture settings. See ‘Control menu layout’ on page 20 for
a table showing the control menu structure and options available.
PWM frequency
You can change the LED dimming PWM frequency using either a DMX command or a
control panel setting in order to avoid flicker and beat frequencies in video images.
The default PWM setting is 582 Hz. You can adjust the PWM frequency continuously
from 582 to 618 Hz, or you can set it to either 1200, 2400, 4800 or 9600 Hz. Note that a
higher PWM frequency may affect dimming performance.
The PWM frequency setting is stored in the fixture and is not affected by cycling power
off and on. However, it will be affected if you use the Factory default command in the
control menus.
You should set all the fixtures in an installation to the same PWM frequency in order to
ensure the same performance. As described above, you can do this using the PWM
frequency selection or Factory default commands in the control menus or using the
PWM frequency DMX channel.
Installation options
The base has M10 threaded holes for direct fastening of half-coupler clamps. A
countersunk M10 bolt for clamp attachment is supplied with the fixture.
Two eyelets are provided for safety cable attachment.
