22 Fusion Creos Quick-Start and Safety Manual
If you need to install a powerCON TRUE1 TOP connector on a power cable, follow
the instructions given in the Support area of the Neutrik website at
www.neutrik.com.
Respect the color coding used in the supplied power cable and in your local mains
power wiring system. US and EU systems use the color coding shown below:
Live or L
Neutral or N
Ground / Earth or
US system
Black
White
Green
EU system
Brown
Blue
Green / Yellow
Connecting multiple fixtures to power in a chain
You can connect fixtures to power in a daisy-chain to simplify your power circuit
layout.
Warning! Do not connect more than two (2) Fusion Creos fixtures in total
to power in one chain at 100-120 V, 60 Hz. Do not connect more than five
(5) Fusion Creos fixtures in total to power in one chain at 200-240 V, 50
Hz.
The power input cable supplied with the fixture is rated 16 A maximum.
Add together the maximum current draw ratings of all the devices that
you intend to connect to power in a daisy chain and do not create a chain
with a total maximum current draw of more than 16 A, or you will create a
risk of fire and electric shock.
To connect fixtures to power in a chain:
Obtain power relay cables that have male and female powerCON TRUE1 TOP
connectors. Cables must be minimum 14 AWG or 1.5mm
2
, rated minimum 16 A
and suitable for the environment and application.
Connect the power input cable to the Mains IN socket of the first fixture.
If you are operating the fixture on 100-120 V, 60 Hz AC mains power, you can
connect maximum one fixture to the mains THRU socket (giving a maximum of
2 fixtures total connected together in a chain) using a power relay cable. Do not
connect any devices to the Mains THRU socket of the second fixture.
If you are operating the fixture on 200-240 V, 50 Hz AC mains power, you can
connect maximum four fixtures to the mains THRU socket (giving a maximum
of 5 fixtures total connected together in a chain) using power relay cables. Do
not connect any devices to the Mains THRU socket of the fifth fixture.
