German Light Products®
Rev. 20241003-03 13
Besides static color presets, the color wheel channel also offers continuous color
scrolling through HSI colors. When set to HSI Scroll, the fixture runs through saturated
HSI colors with variable speed from slow to fast.
The crossfade time of a color change is relative to the speed: at slow speeds colors
crossfade smoothly and at fast speeds colors snap.
If a color coordinate is outside the possible color gamut of the light source, the fixture
tries to match the target color as closely as possible.
Note: Color wheel color presets have higher priority than the Color Mix, CTO and M/G
Shift channels.
The virtual color wheel channel must be set to DMX 000 in order to use normal RGB,
RGBL or x:y color mixing.
Tungsten simulation
When a tungsten lamp is dimmed, there is a small delay in intensity changes and there
is a color shift along the black body line. The tungsten simulation channel allows the
user to select between different tungsten options in all three Color Mix modes.
The first part of the Tungsten channel offers standard tungsten features with fixed color
temperature, red shift and delayed intensity changes. The color temperature as well as
the color shift and inertia of the selected light source are fully simulated. Tungsten
mode has higher priority than the color wheel or CTC.
The second part of the Tungsten channel lets you apply one of the corresponding
tungsten effects (inertia and intensity) to the currently set mixed color or currently
selected color temperature on the CTC channel.
Note: The Tungsten simulation channel affects the entire fixture. Setting the Tungsten
channel to a specific value will affect the output of the Main module and Sub module.
Shutter
The fixture’s shutter channel offers continuous blackout, continuous open and a range
of intensity effects.
Depending on the selected Sub Module Mode, the shutter channel of the Main module
channel group acts as either a master shutter or as the shutter channel of the Main
module independently of the Sub module.
The following shutter effects are available:
● Single flash performs exactly one single flash with each value change within this
DMX value slot.
● Pulse dims up and down smoothly with the same fade-in and fade-out times. Speed
can be adjusted from slow to fast.
● Pulse open fades in and then snaps to blackout. Speed can be adjusted from slow to
fast.
● Pulse close fades out and then snaps to full. Speed can be adjusted from slow to
fast.
● Strobe double flash provides a quick double flash. Speed can be adjusted from slow
to fast.
