German Light Products® GLP ArenaLED1 Touring
Rev. 20241104-01 19
6. Features
The ArenaLED1 Touring fixture is the perfect solution for professional sports and
event venues, as well as for all types of large events that want dynamic, innovative
lighting for unforgettable visitor experiences. In addition to the standard
conventional basic lighting, dynamic and color-dynamic sceneries can also be
integrated at any time.
As a touring version of the ArenaLED system with a single light head, it has an
integrated power supply and DMX connection. This makes it ideal for large events
and sports events where fast, flexible solutions are required.
The ArenaLED1 Touring is available in two versions:
• The ArenaLED1 Touring White has 36 x 6W LEDs with a native color
temperature of 5700 K. The spotlight offers a luminous flux of 18,800 lm, with
boost up to 24,900 lm, with CRI 85+ and TLCI 80+. The beam angle of 15°/15°
(50%) and field angle 27°/27° (10%) ensures homogeneous illumination.
• The ArenaLED1 Touring Color has 9 x 40W RGBL LEDs with a calibrated white
point of 5700 K. The spotlight offers a luminous flux of 5720 lm, with boost up to
7,620 lm, with CRI 85+ and TLCI 80+. The beam angle of 9.9°/9.5° (50%) and field
angle 23°/22° (10%) ensures homogeneous, colorful illumination.
Fixture intensity and fixture color (in the color version) can be controlled using a
standard DMX-512 controller. Using DMX, you can create static scenes with
brightness and white or color control depending on model, and you can implement
dynamic sequences.
The GLP ArenaLED1 Touring is designed without any external display or buttons to
protect the fixture from tampering.
The most important fixture settings can be adjusted using the fixture’s DMX control
channel or RDM. Basic settings such as the fixture’s DMX address can be adjusted
using RDM.
The ArenaLED1 Touring mounting yoke makes fixture mounting and aiming easy.
The yoke can be permanently mounted on a structure or surface using a bolt or
screwbolt passed through its 13 mm hole, or it can be temporarily fastened to a
structure using a GLP standard Omega bracket. These options make the fixture
suitable for both permanent and temporary installations.
DMX start address
Before controlling the fixture using DMX, you need to set its DMX start address
using RDM.
DMX control modes
Select the control mode (DMX control channel layout) that you want to use:
ArenaLED1 Touring White
• Mode 1 – Most simple DMX control mode, with 8-bit Intensity channel and a
Control/Settings channel for adjusting fixture settings.
