www.glp.de GLP ArenaLED1 Touring
20 GLP ArenaLED1 Touring Safety and User Manual
• Mode 2 - Advanced DMX control mode, with 16-bit Intensity channel, a
Control/Settings channel for adjusting fixture settings and two additional
channels for Intensity effects (Shutter FX select channel) and speed (Shutter FX
speed channel).
NB: In firmware v. 0.5.0 not all Shutter FX are fully implemented in DMX
Mode 2. Some FX may not work as intended. Some Control/Settings
channel commands are not fully implemented.
ArenaLED1 Touring Color
• Mode 1 - Most simple DMX control mode, with 8-bit Intensity channel,
Control/Settings channel for adjusting fixture settings, Color Temperature
channel and Color Mixing channel.
NB: In firmware v. 0.5.0, it is only possible to adjust Lime individually
when at least one other RGB color DMX value is greater than 1.
• Mode 2 - Advanced DMX control mode, with 16-bit Intensity channel,
Control/Settings channel for adjusting fixture settings, Color Temperature
channel, Tungsten effects, Color Mixing channels and two additional channels
for Intensity effects (Shutter FX select channel) and speed (Shutter FX speed
channel).
NB: In firmware v. 0.5.0 not all Shutter FX are fully implemented in DMX
Mode 2. Some FX may not work as intended. The Tungsten and CTC
channels are available but not fully implemented. Some Control/Settings
channel commands are not fully implemented.
Control Channels
Intensity / Dimmer channel
The Intensity channel controls the output intensity of the fixture with 8- or 16-bit
resolution. Different dimming curve options are available (see ‘Dimmer Curves’ on
page 23).
Shutter FX Select channel
This channel lets you select between open (DMX 000) or different Intensity effects
(shutter effects).
NB: Not all Shutter FX are fully implemented in firmware v.0.5.0.
• Single Flash – The fixture flashes once each time you change the value on the
speed channel.
• Strobe Sync - You can adjust the strobe rate using the speed channel.
• Strobe Random - Flashes at random intervals across multiple fixtures. All the
pixels on one fixture flash together. Set flash intensity, duration, and rate as
normal.
• Double Flash - Quick Double Flashes that are synchronized across multiple
fixtures on the same DMX link. Set intensity and rate as normal. Duration is not
adjustable.
