German Light Products®    GLP ArenaLED1 Touring
  Rev. 20241104-01  15
Installing on a surface at any angle
To install the fixture on a surface at any angle:
  Check that the surface is secure and can safely hold the weight of the fixture
plus all hardware and cables. Fasteners must be suitable for their purpose and
the installation environment.
  Fasten the mounting yoke to the surface by passing a suitable fastener such as a
grade 8.8 steel bolt or screwbolt through the 13 mm hole in the yoke (see I in
Figure 3) and fastening it to the surface. Adjust the aim of the fixture before
tightening the fastener.
  Loosen the tilt adjustment handles (H in the fixture overview drawing on page
13) on either side of the mounting yoke, tilt the fixture to aim it correctly and re-
tighten the handles.
  In a temporary installation, secure the fixture with a safety cable as described in
‘Securing the fixture with a safety cable’ on page 14 if there is any risk that the
fixture will cause injury or damage if it falls.
Installing on a rigging truss or similar structure
You can suspend the fixture from a rigging truss or pipe using a rigging clamp
bolted to a suitable omega bracket that is fastened to the fixture’s mounting yoke.
If you are going to install the fixture hanging vertically downwards from a horizontal
rigging truss or pipe, you can fasten it to the truss using a G-clamp. If you are going
to install the fixture in any other orientation, you must use a half-coupler clamp that
completely encircles the truss chord or pipe.
  Attach a suitable rigging clamp to a GLP standard 89 mm Omega Bracket.
  Fasten the omega bracket to the fixture’s mounting yoke by inserting the
camlock fasteners into the camlock receptacles (J in Figure 3) in the mounting
yoke and turning the handles on the camlock fasteners a full 90 degrees
clockwise to lock them.
  Fasten the rigging clamp to the truss or structure with the fixture facing towards
the area to be illuminated.
  Secure the fixture with a safety cable as described in ‘Securing the fixture with a
safety cable’ on page 14.
  Loosen the tilt adjustment handles (H in the fixture overview drawing on page
13) on either side of the mounting yoke, tilt the fixture to aim it correctly and re-
tighten the handles.
