10
Installation
GGF Series Gas Fryer
2.7.1 Typical Gas Supply Line Connection
* 1/2” Flexible
Gas Line
* Secondary In
Line Regulator
[May not be
required, see
below]
To Fryer
Regulator
* Customer supplied
* Gas Supply Shut
Off Valve
IMPORTANT!
• Installation must comply with local code, or in the absence of local code, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 [in Canada, Natural Gas & Propane Installation Code, CSA B149.1] including:
• The appliance must be disconnected from the incoming gas supply line at the main shutoff valve, during any
testing of piping at test pressures in excess
of 1/2 psi (3.5kPa).
• The appliance must be isolated from the incoming gas supply line by closing the fryer gas shutoff valve, during
any testing of piping at test pressures equal to or less than
1/2 psi (3.5kPa).
1. Check pressure on incoming gas supply & compare to Table 2.5.2. If necessary install a secondary pressure
regulator to regulate supply pressure to a maximum of 13.85” W.C. [3.45 kPa].
2. Install an appropriate quickcoupling fitting on the gas line.
3. Connect an approved 1/2” flexible gas line (not provided, purchased separately) between supply line & fryer gas
regulator located on rear of the unit.
Note: The flexible gas line should be long enough to allow for the fryer to be moved away from wall for any
servicing & cleaning.
4. WHEN TIGHTENED, CHECK ALL CONNECTIONS FOR LEAKS USING A SUITABLE METHOD!
Continued on Next Page
* Quick Disconnect
