9
Installation
GGF Series Gas Fryer
2.6. Electrical Connections
IMPORTANT!
When installed, appliance must be electrically grounded in accordance with local code, or in the absence of local
code, with the National Electrical Code, ANSI/NFPA 70, or Canadian Electrical Code, CSA C22.2, as applicable.
2.7. Gas Line Connection
Verify that a proper facility gas supply line (1/2” min.) is install & equipped with a “service” shut‐off valve (not
provided). See Section
2.8.1, Typical Gas Supply Line Connections.
• Combustion gases produced by this appliance must be vented to the outside in accordance with the prevailing
National
Fuel Gas Code, ANSI Z223.1 & terminate with a UL listed outside vent terminal. For Canadian
installations reference CSAB149.1
or .2, Installation Codes for Gas Burning Appliances and Equipment
.
•
Quickdisconnect devices must comply with the Standard for QuickDisconnect Devices for Use with Gas Fuel,
ANSI Z21.41 [in Canada CSA 6.92014].
• Gas connectors & supply lines must comply with Standard for Movable Gas Appliance, ANSI69, and Addenda
Z21.69 [in Canada CSA 6.102015].
• The unit MAY
require installation of a secondary inline gas pressure regulator (customer supplied), see Section
2.5, Utility Requirements & Table 2.5.2, Fuel Gas Specifications.
• The unit MUST
be connected to gas supply by qualified gas service personnel.
• Ensure both the facility shutoff valve & the fryer shutoff valve are in the [OFF] position.
Continued on Next Page
1. Connect fryer power cord to an appropriately grounded, isolated, 120V,
15A (min), nonGFCI receptacle
... See Table 2.5.1.
2. Fryer has a 6 ft. power cord with a molded NEMA 515P plug.
3. Because the fryer’s electronic gas ignitor system is designed to arc to
ground to ignite the burners, it is necessary that only a nonGFCI
receptacle be used for power. The ignitor will cause a GFCI to trip and
interrupt fryer power. To avoid such nuisance interruptions DO NOT
connect the appliance to a GFCI receptacle.
