13
DANGER!
Risk of injury
If the product is used without a safety guard, you and bystanders may
be injured by ying parts.
Use the product only when the safety guard is tted.
Wear safety goggles.
Keep bystanders at a distance.
DANGER!
Risk of injury
The operating noise of the product during use may damage your
hearing.
Wear hearing protection when using the product.
3.6.1 Starting up the weed brush
1. Check for small stones in the weed brushes before starting. Remove
them if any are present.
2. Insert the battery
B
into the battery holder
D
until you hear it engage.
3. Place the cordless weed brush parallel to the guide wheel and brush
on the joint to be cleaned. Hold the cordless weed brush at the
working angle and make sure that the rubber lip on the protective
hood is just above the ground.
4. Press the safety lock
11
with one nger and hold the cordless weed
brush with one hand on the handle
6
and the other hand on the
auxiliary handle
7
.
5. Pull the start lever
12
towards the handle
6
.
The cordless weed brush will start and the battery state of charge
indicator
P
will be displayed for 5 seconds.
3.6.2 Stopping the weed brush
1. Release the start lever
12
.
The cordless weed brush stops.
2. Press the release button
A
and remove the battery
B
from the battery
holder
D
.
3.7. Adjusting the weed brush rotation speed [Fig. O7]
You can variably adjust the rotation speed of the weed brush from
min. 700 to max. 1800 RPM .
Turn the power regulator
13
to the desired position.
4. MAINTENANCE
DANGER!
Risk of injury
If the product starts accidentally, people can be injured by the
weed brush.
Remove the battery before servicing the product.
Do not touch moving parts.
4.1. Cleaning the weed brush [Fig. M1]
DANGER!
Risk of injury and damage to property
Not cleaning the product properly can injure people and damage the
product.
Do not use water or a water jet (especially a high-pressure water jet)
to clean the product.
Do not use chemicals, including gasoline or solvents, to clean
the product. Some of these substances can destroy important
plastic parts.
The ventilation slots must always be kept clean.
1. Use a damp cloth to clean the cordless weed brush.
2. Use a soft brush to clean the ventilation slots
14
. Do not use a
screwdriver.
3. Clean all moving parts after each use.
3.2.2 Battery state of charge indicator
P
on the product
[Fig. O4/O7]
After starting the product, the battery state of charge indicator
P
is
displayed for 5 seconds.
Battery state of charge indicator Battery state of charge
L1
,
L2
and
L3
illuminated green
67–100% charged
L1
and
L2
illuminated green
34–66% charged
L1
illuminated green
11–33% charged
L1
ashes green
0–10% charged
If the LED
L1
ashes green, the battery must be charged.
If the error LED
Wp
is illuminated or ashing, see “6. TROUBLESHOOTING”.
3.3. Working position [Fig. O5]
Hold the cordless weed brush in an upright position with one hand on
the handle
6
and the other hand on the auxiliary handle
7
.
3.4. Adjusting the position of the auxiliary handle
[Fig. O6]
DANGER!
Risk of injury
Adjusting the auxiliary handle poses a risk of pinching your ngers.
Mind your ngers when adjusting the auxiliary handle.
The position of the auxiliary handle can be adjusted incrementally to
your height.
When the cordless weed brush is correctly adjusted to your height, your
posture will be upright and the weed brush will touch the surface to be
cleaned in the working position.
1. Pull the lever
8
.
2. Tilt the auxiliary handle
7
to the desired position.
3. Release the lever
8
again until it locks.
3.5. Adjusting the length of the shaft [Fig. O6]
DANGER!
Risk of injury
When the shaft is fully retracted (transport position), the handle is too
close to the brushes.
Only start the cordless weed brush with the shaft extended.
The length of the shaft can be continuously adjusted to the height of
the body.
1. Loosen the clamping sleeve
9
.
2. Pull out the shaft
10
to the required length.
3. Tighten the clamping sleeve again
9
.
3.6. Starting/stopping the cordless weed brush
[Fig. O1/O5/O7]
DANGER!
Risk of death
If you damage cables which are not immediately visible whilst using the
product, it can lead to injury or death.
Check the work area for hidden cables before using the product.
Remove them if necessary.
Keep bystanders at a distance.
Wear safety shoes.
DANGER!
Risk of injury
If the product does not stop when the start lever is released, people
can be injured.
Do not bypass the safety devices or switches. For example, do not
attach the start lever to the handle.
en
