3. TROUBLESHOOTING
3-7
412525, 1 Sensor(LAN) Buffer
Overflow
Serial, analog and digital data
from Sensor Adapter are not re-
corded to Fixed DRU, Float-free
DRU and Long Term Device.
If the error re-occurs, contact
your dealer.
412527, 1 Image(LAN) Buffer
Overflow
Image data from RADAR/EC-
DIS are not recorded to Fixed
DRU, Float-free DRU and Long
Term Device.
412531, 1
to
412538, 1
No No.x Sensor
Adapter Connection
(x: 1 - 8)
No. x Sensor Adapter is missing
(x: 1 - 8).
Contact your dealer.
412541, 1 No No.1 VIDEO LAN
Converter Connection
No.1 VIDEO LAN Converter is
missing.
412542, 1 No No.2 VIDEO LAN
Converter Connection
No.2 VIDEO LAN Converter is
missing.
412581, 1
to
412583, 1
No No.x ECDIS
Attached information
Input (No.1 - No.3)
No.x ECDIS has been powered
off and the attached information
is not received (x: 1 - 3).
Turn on the No. x ECDIS
(x: 1 - 3). If the error re-occurs,
contact your dealer.
412601, 1 No Radar1 Recording
Image Input
Image input channel that is not
valid for No.1 Radar setting is
set.
Turn on the No. 1 or No. 2 Ra-
dar. If the error re-occurs, con-
tact your dealer.
412602, 1 No Radar2 Recording
Image Input
Image input channel that is not
valid for No.2 Radar setting is
set.
412603, 1 No ECDIS Recording
Image Input
Image input channel that is not
valid for ECDIS setting is set.
Turn on the ECDIS. If the error
re-occurs, contact your deal-
er.
412604, 1 No Additional Record-
ing Image Input
Image input channel that is not
valid for Additional setting is
set.
Turn on the additional units. If
the error re-occurs, contact
your dealer.
412605, 1 No General1 Record-
ing Image Input
Image input channel that is not
valid for No.1 General setting is
set.
Turn on the No. 1 or No. 2
General. If the error re-occurs,
contact your dealer.
412606, 1 No General2 Record-
ing Image Input
Image input channel that is not
valid for No.2 General setting is
set.
412611, 1
to
412614, 1
No. x Radar Unrecog-
nized Image (x: 1 - 4)
VDR does not support the for-
mat of image data from No. x
Radar (x: 1 - 4).
Contact your dealer.
412615, 1
to
412617, 1
No.x ECDIS Unrecog-
nized Image (x: 1 - 3)
VDR does not support the for-
mat of image data from No. x
ECDIS (x: 1 - 3)
412801, 1
to
412816, 1
No yy
(yy: Equipment name)
No. xx serial channel has not
received correct format data
from a connected serial device
(xx: 01 - 16).
Check the equipment name
on the RAP and confirm that
the applicable sensor is oper-
ating correctly. If the sensor is
operating correctly, contact
your dealer.
412817, 1
to
412880, 1
No yy
(yy: Equipment name)
No. xx sensor (LAN) channel
has not received correct format
data from a connected sensor
(LAN) device (xx: 01 - 64).
412901 Liveplay Not Available The live play is not available be-
cause the remote playback
function is activated.
Deactivate the remote play-
back function to use the live
play function.
ID Title Description Action
